Steel forming machine series, furring channel forming machine

FOB Price

USD $7,200.5 - $14,200.5 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Type:	Tile Forming Machine	Tile Type:	Steel
Use:	Roof	Production Capacity:	30m/min	Place of Origin:	Hebei, China
Brand Name:	Xingbo	Model Number:	Roll Forming Machine	Power(W):	3 Kw
Voltage:	380v 50Hz	Dimension(LWH):	as design	Weight:	3.2T
Certification:	CE ISO	Warranty:	1 Year	After-sales Service Provided:	Engineers available to service machinery overseas

Steel forming machine series,furring channel forming machine

Features and Structure:

furring channel forming machine

* Multi-functional converter controlled speed regulation by PLC

* Main-machine interface touch screen for easy operation

* The machine can be used for different type of stud and track

*Automatic electric control system make production safety ang efficiency

*Solid shaft and high quality rollers make the machine working smoothly and endurable

*Low noise,low wasting ,energy saving and environmental

Product Description

1.Processing flow :

2.Technical Parameters:

furring channel forming machine

Equipment operation	Automatically
Voltage	380V,50/60Hz or at buyer's request
Thickness of material sheet	0.3----1.5mm(normally)
Width of material sheet	As drawing
Control system	By PLC
Cutting method	Hydraulic cutting
Material of roller station	Gcr12 with hard treatment
Formed width	As drawing
Working speed	20m/min
Length of finished product	set in computer, machine will cut automatically
Transmission type	gears

A.Decoiler

B.Main forming machine

C.PLC Control box

D.Cutting parts

Packaging & Shipping

Delivery

we will arrange shipment within 35days after receipt of deposit

Hebei Feixiang Roll Forming Machinery Co., Ltd.: Contact nameSam Li; Phone86-317-5569916 8297121; AddressNo. 88, Yingbin Road, Industrial Development Zone
