FX omega grafting machine
Technical specifications
Meterial :#45 steel
package: simple waterproof
The min order:one set
Freight way: container
Term of payment: T/T
Strong point: debuging all the world, the best price
1.The chart of process flow:
Decoiling--active feeding---forming---measuring lengh---cutting---product to stand
2.Main equipment:
Decoiler,main forming machine,hydraulic cutting,electric system(plc),hydraulic system,product stand.
3.Technical parameters
1)Profile
A.thickness:0.3--0.8mm
B.Feeding width:100mm
2)inner tight decoiler
il inner diameter:450mm--550mm
B.max width of coiling:400mm
C.max weight of loading:1500kg
3)main forming machine
A.Shaft material:45# steel,bearing steel outer diameter 85mm
B.Main motor power:5.5kw
C.Forming speed:8--10m/min
D.Voltage:380v,50hz
E.Roller station:11
4)cutting system
A.hydraulic cutter
B.Blade and mould material:Cr12 steel with quenched treated 60-62
Cutting system advanced hydraulic drive,after automatic cutting after forming.no
5)control system
A.PLC: taida form Taiwan
B.Coder:from south korea
