Home > Products > camper float > Human quarter 2 horse trailer angle float
Human quarter 2 horse trailer angle float
US$ 6,000 - 8,000
/ Unit
1 Unit(Min. Order)
- qingdao
- T/T
You May Like
Product Details
| OEM No. | STD-2HAL-D | Max Payload | 2500KG | |
| Size | 5000 x 2480x 2590MM | Place of Origin | Shandong, China | |
| Brand Name | STANDARD | Model Number | STD-2HAL-D |
Product Description
Specification:
| Model | STD-2HAL-D |
| Materials | Chassis Material: double hot dip galvanized RHS (3.5mm-4.0mm) |
| Frame Material: double hot dip galvanized RHS (2.5mm) | |
| Body Panel: galvanized sheet (1-1.5mm) | |
| Roof: Special molded FRP 3mm | |
| Brake | double axle electric brakes |
| Drawbar | Drawbar Checker Plate 1.2mm aluminium |
| Drawbar Safety Chain two & Bracing Wheel one | |
| Suspension | Roll rocker tandem spring 8 plate |
| Axles | Two special trailer axles 50*50mm |
| Wheels & Tyre | Five 195R14 tyres and 14’ aluminum alloy rims including a spare wheel |
| Rubber Matting | 18mm special plywood for floor& ramp door |
| Rubber Matting For Inner Side Panel 6mm Rubber Matting | |
| Rubber Matting For Floor & Ramp Door 17.5mm anti-slip rubber sheet | |
| Windows& Doors | Front Window (mm) 1220*610mm |
| Side Windows 6 Drop-down windows 3 | |
| Vents two large size upturning ventilation windows | |
| Rear Upper Door (mm) 1980*1065 Strut & High-intensity anti-rust strut | |
| Ramp Door (mm) 2030*1210 | |
| Side Door (mm) 1730*615 | |
| Hinges for Rear Upper Door special 6mm diameter copper hinges | |
| Supporting Wheel | Swing-able knight supporting wheels to make parking safe and reliable |
| Lights& Retro Reflectors | Trailer Plug Seven-prongs plug |
| Rear Lights brackets aluminium | |
| LED interior lights, two small LED sidelights, two LED combination taillights | |
| Retro Reflectors 8 | |
| Auxiliary Fittings | Cupboard Front |
| Horse Protection Frame fully padded | |
| Horse Ring 6 | |
| Saddle Rack in saddle box(1200mm height for 2 saddles) | |
| Rug Rack Side | |
| Saddle Box One | |
| Dimensions | Body Dimension (L x W x H: mm) : 5000 x 1980 x 2230 |
| Inner Dimension (L x W x H: mm) : 4975 x 1930 x 2155 | |
| Overall Dimension (L x W x H: mm): 5850 x 2480 x 2590 | |
| Length of Tone (mm): 850 | |
| Empty Weight | 1800 KGs |
| Carrying Capacity | 2500 KGs |
