Two Horse Float With Living Quarters

Two Horse Float With Living Quarters thumbnail-1
Two Horse Float With Living Quarters thumbnail-2
Two Horse Float With Living Quarters thumbnail-3
Two Horse Float With Living Quarters thumbnail-4
Two Horse Float With Living Quarters thumbnail-5
Two Horse Float With Living Quarters thumbnail-6
Two Horse Float With Living Quarters photo-1
Two Horse Float With Living Quarters photo-2
Two Horse Float With Living Quarters photo-3
Two Horse Float With Living Quarters photo-4
Two Horse Float With Living Quarters photo-5
Two Horse Float With Living Quarters photo-6
US$ 6,000 - 8,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
OEM No.:
STD-2HAL-D
Max Payload:
2500KG
Size:
5750 x 2500 x 2590MM
Contact Supplier Request Quote Chat Now
Shandong Standard Trailer Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
OEM No. STD-2HAL-D
Max Payload 2500KG
Size 5750 x 2500 x 2590MM
Place of Origin Shandong, China
Brand Name STANDARD
Model Number STD-2HAL-D

Specification:



Model STD-2HAL-D
Materials Chassis Material: double hot dip galvanized RHS (3.5mm-4.0mm)
  Frame Material: double hot dip galvanized RHS (2.5mm)
  Body Panel: galvanized sheet (1-1.5mm)
  Roof: Special molded FRP 3mm
Brake double axle electric brakes
Drawbar Drawbar Checker Plate 1.2mm aluminium
  Drawbar Safety Chain two & Bracing Wheel one
Suspension  Roll rocker tandem spring 8 plate
Axles Two special trailer axles 50*50mm
Wheels & Tyre Five 195R14 tyres and 14’ aluminum alloy rims including a spare wheel
Rubber Matting 18mm special plywood for floor& ramp door
  Rubber Matting For Inner Side Panel            6mm Rubber Matting
  Rubber Matting For Floor & Ramp Door     17.5mm anti-slip rubber sheet
Windows& Doors Front Window (mm) 1220*610mm
  Side Windows   6       Drop-down windows 3
  Vents     two large size upturning ventilation windows
  Rear Upper Door (mm) 1980*1065  Strut & High-intensity anti-rust strut
  Ramp Door (mm)  2030*1210
  Side Door (mm)   1730*615
  Hinges for Rear Upper Door    special 6mm diameter copper hinges
Supporting Wheel Swing-able knight supporting wheels to make parking safe and reliable
Lights& Retro Reflectors Trailer Plug        Seven-prongs plug
  Rear Lights brackets aluminium
  LED interior lights, two small LED sidelights, two LED combination taillights
  Retro Reflectors  8
Auxiliary Fittings Cupboard    Front
  Horse Protection Frame  fully padded
  Horse Ring     7
  Saddle Rack   in saddle box(1200mm height for 3 saddles)
  Rug Rack       Side
  Saddle Box    One
Dimensions Body Dimension (L x W x H: mm) :   4900 x 1980 x 2230
  Inner Dimension (L x W x H: mm) :   4875 x 1930 x 2155
  Overall Dimension (L x W x H: mm):  5750 x 2500 x 2590
  Length of Tone (mm):    850
Empty Weight 1700 KGs
Carrying Capacity 2500 KGs




Two horse float with living quartersTwo horse float with living quartersTwo horse float with living quartersTwo horse float with living quartersTwo horse float with living quartersTwo horse float with living quarters
