Band Saw For Metal Cutting BS-128DR Portable Band Sawing MachineUS$ 1,000 - 10,000MOQ: 1 Set
-
Band Saw For Metal Cutting BS-115A Sawing MachineUS$ 1,000 - 10,000MOQ: 1 Set
-
Band Saw For Metal Cutting BS-115 Sawing MachineUS$ 1,000 - 10,000MOQ: 1 Set
Band Saw For Metal Cutting BS-180G
Features:
1. The European design band saw features European design, dovetail-type clamp movement and locking mechanism.
2. The European design band saw features double-speed selection.
3. The saw bow can be rotated from 0° to 45°. It has the characteristics of worm gear box transmission structure.
4. The calibration of the jaw is convenient for adjustment and positioning at any angle.
5. The falling speed of saw bow is controlled by hydraulic cylinder.
6. The European design band saw has a sizing device (the machine will automatically stop after sawing the materials).
7. The European design band saw has a power break protection device (the machine will automatically power off when the rear protective cover is opened).
8. The cooling system of the European design band saw can prolong the service life of saw blade and improve the precision of the workpiece.
9. It is equipped with a block feeder (with fixed sawing length).
Specification:
Model |
|
BS-180G |
Capacity |
Circular @90° |
180mm(7”) |
Rectangular @90° |
180x260mm (7”x10”) |
|
Circular @60° |
- |
|
Rectangular @60° |
- |
|
Circular @45° |
105mm(4”) |
|
Rectangular @45° |
120x105mm (4.75”x4”) |
|
|
@60Hz |
39,66,82 MPM |
|
@50Hz |
34,55,66 MPM |
Blade size |
20X0.9X2362mm |
|
Motor power |
750W 1PH(3PH), 1.1KW 1.5HP(1PH) |
|
Drive |
Gear |
|
Packing size |
131x57x113cm |
|
N.W./G.W. |
180/210kg |
|
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
