Band Saw For Metal Cutting BS-115A
Features:
1. The maximum processing capacity is 115 mm (4.5”).
2. Light-weight design, suitable for field and construction site application
3. This band saw features a belt drive and 3-speed conversion.
4. The saw bow can rotate from 0° to 45°, and can be used vertically and horizontally.
5. It features quick and fixed clamping and is equipped with a block feeder (with fixed sawing length)
6. With a sizing device, machine will stop automatically after sawing materials.
Specification:
| Model | BS-115 | BS-115A | |
| Capicity | Circular @90° | 115mm(4.5") | 115mm(4.5") |
| Rectangular @90 ° | 100x150mm(4"x6") | 100x150mm(4"x6") | |
| Circular @45° | 100mm(4") | 100mm(4") | |
| Rectangular @45 ° | 60x100mm(2.4"x4") | 60x100mm(2.4"x4") | |
| Blade speed | @ 60HZ | 24,35,61MPM | 24,35,61MPM |
| @ 50HZ | 20,29,50MPM | 20,29,50MPM | |
| Blade size | 13x0.6x1538mm | 13x0.6x1638mm | |
| Motor power | 375W 1/2HP(3PH),550W 3/4HP(2PH) | ||
| Dirve | V-belt | V-belt | |
| Packing size | 970x460x460 | 1080x480x560 | |
| N.W./G.W.(kg) | 68/72kg |
76/95kg |
|
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
