Help CenterABS 300 NC Fully Automatic Miter Band Saw Automatic Band Saw With Programmable Cutting Angle
Related Products
-
B 200 S Miter Band Saw Band Saws - an Economic Alternative to Frame and Circular SawsUS$ 1,000 - 10,000MOQ: 1 Set -
B 125 S Miter Band Saw Band Saws - an Economic Alternative to Frame and Circular SawsUS$ 1,000 - 10,000MOQ: 1 Set
-
ABS 280 B Fully Automatic Band Saw Fully Automated for Continuous Operation - Proven Reliability,NegotiableMOQ: 1 Set
-
Fully Automated High-performance Band Saws ABS 460L More Automation, Faster Cuts and Less Down-timeUS$ 1,000 - 10,000MOQ: 1 Set
-
Hydraulic Hacksaw Machine G7132 Metal Cutting SawUS$ 5,000 - 7,000MOQ: 1 Set
Feature:
1.Cutting angle settings 0° - 45°
2.Robust touch screen control panel
3.Automatic workpiece feed
4.Torsion-resistant dual-column construction
5.Hydraulic saw frame feed via chrome-plated column guide
6.Shtly inclined saw frame improves cutting performance and increases the service-life
7.Dual hydraulic workpiece clamping
8.Infinitely variable cutting speed
9.Automatic angle positioning in 1° increments from 0° to 45°
10.Hydraulic bundle vise for both vises included with standard equipment
11.Precise and stable saw band guides ensure high angular accuracy
12.Automatic band breakage control
13.Band speed indicator on the display
Specification:
| Model | ABS 300 NC |
| Cutting capacity 0° (flat) | 360x300 mm |
| Cutting capacity 0° (round) | 300 mm |
| Cutting capacity 0° (square) | 300 mm |
| Cutting capacity 30° (flat) | 300x300 mm |
| Cutting capacity 30° (square) | 300 mm |
| Cutting capacity 30° (round) | 300 mm |
| Cutting capacity 45° (flat) | 240x300 mm |
| Cutting capacity 45° (square) | 240 mm |
| Cutting capacity 45° (round) | 240 mm |
| Cutting length | 400 mm |
| Cutting speed | 20 - 90 m/min |
| Motor rating main drive | 3 kW |
| Motor rating hydraulic pump | 0,75 kW |
| Motor rating coolant pump | 0,45 kW |
| Belt dimensions | 4.430x34x1,1 mm |
| Overall dimensions (length x width x height) | 2.200x2.000x1.700 mm |
| Weight | 1.900 kg |
Standard Equipment:
Siemens PLC control, autom. cleaning brush, feed roller table (2 meters), 1 saw blade, touch screen monitor, manual central lubrication, automatic parts counter, bundle vise, chip conveyor, coolant system, operating tools, operator manual
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
