Help CenterABS 280 B Fully Automatic Band Saw Fully Automated for Continuous Operation - Proven Reliability,
Related Products
-
Fully Automated High-performance Band Saws ABS 460L More Automation, Faster Cuts and Less Down-timeUS$ 1,000 - 10,000MOQ: 1 Set -
Hydraulic Hacksaw Machine G7132 Metal Cutting SawUS$ 5,000 - 7,000MOQ: 1 Set
-
Factory Promotion Sale Price GH4228A Double Column Horizontal Automatic Band Saw MachineUS$ 2,400 - 2,600MOQ: 1 Set
-
Hydraulic Hacksaw Machine HS7150 Metal Cutting SawUS$ 5,000 - 7,000MOQ: 1 Set
-
GH42100 Automatic Band Sawing Machine Used Cutting MetalUS$ 22,000 - 24,000MOQ: 1 Set
Feature:
1.Saw frame and machine bed are made of premium cast-iron for torsion-free performance even under maximum loads
2.New helical gears ensure above-average service life and low maintenance
3.Infinitely variable saw frame feed
4.Large size hydraulic cylinder for constant quiet operation
5.Automatic adjustment of cutting height
6.A bundle vise is provided for cutting entire material packs to length
Specification:
|
Model |
ABS 280 B |
| Roller guide length | 1.200 mm |
| Feed rollers | 4 Pieces |
| Cutting capacity 90° (flat) | 250x280 mm |
| Cutting capacity 90° (round) | 280 mm |
| Cutting capacity 90° (square) | 270 mm |
| Stop length | 500 mm |
| Cutting speed | 20 - 100 m/min |
| Motor rating main drive | 1,5 kW |
| Supply voltage | 400 V |
| Motor rating hydraulic pump | 0,37 kW |
| Motor rating feed | 0,25 kW |
| Belt dimensions | 27x0,9x3.400 mm |
| Overall dimensions (length x width x height) | 1800x850x1200 mm |
| Weight | 600 kg |
| Motor rating coolant pump | 0,12 kW |
Standard Equipment:
Automatic band break control, bundle vise, coolant system, saw-band, operating tools, chip wiper, feed roller table 1,2 m, operator manual
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
