Labware

Specifications

• labware


Specification:

Lab Furniture(Steel structure)

Desktop: Chemical-resistant laminate (SPC), 12.7mm thickness. Erosion-resisting, water-proof, heat-resisting (140°C),the rim of the edge is thickened to avoid water to flow into the cabinet, it’s easy to clean and maintenance.

Cabinet:  The framework is made of 1.2mm thickness cold rolled steel sheet and the surface is coated with epoxy painting. Erosion-resisting, heat-resisting. The height of baffle in the cabinet can be adjusted up and down in 13mm range. Double sound-proofing material is used in the cabinet door.

Channel: Three stainless steel slide rails with plastic wheel, can load 15Kg(>100000 times). Anti-rebound, self-locking. Anti-collision washer on the surface of drawer.

Hinge: Concealed, coated with epoxy painting, self-closing, and opening angle is 180°.

Handle: SS “D” type.

Moveable baffle plate: Removed easily to enter service access.

Test-tube rack: Be made of three parts as below:

A: Table rectangular pillar 720mm in height;

B: Functional Module W*H 150mm*300mm;

C: Baffle plate: 1200mm, 1500mm, 1800mm in length and 300mm in width, be used for different size tubes, instruments and chemical reagent.
