DVR-7014KS 4 Channel CCTV DVR Kit H. 264 4x Outdoor Waterproof Night Vision IR Cameras

DVR-7014KS 4 Channel CCTV DVR Kit H. 264 4x Outdoor Waterproof Night Vision IR Cameras thumbnail-1
DVR-7014KS 4 Channel CCTV DVR Kit H. 264 4x Outdoor Waterproof Night Vision IR Cameras photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Ruiye
Model Number:
DVR-7014KS
Contact Supplier Request Quote Chat Now
Shenzhen Rui Ye Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Ruiye
Model Number DVR-7014KS



DVR Feature:
H.264 Baseline compression
Video Input: NTSC / PAL : BNC 4CH In / 1CH Out
Audio: 4CH in, 1CH out; Alarm: 4ch in / 1ch out; 1CH VGA output
Hexaplex operation - simultaneous record, live, playback, backup, control, & remote access
Display Resolution: NTSC : 720x480 ; PAL: 720x576
Recording Rates and Resolution: NTSC : NTSC : 30/720x480; 60/720x240; 120/360x240;PAL : 25/720x576; 50/720x288; 100/360x288
Recording Time: 7~20 days with 500GB HD for Continuous Recording mode @ 25 fps



DVR SPECIFICATION:



Model

4 CHANNEL

8 CHANNEL

Operation System

Embedded Linux Operation System

Operation Interface

GUI, support mouse, pane, remote control operation

Video Standard

PAL, NTSC

System Resources

Multi-tasking operation, simultaneous multi-channel recording, simultaneous video playback and simultaneous network operation.

Video Compression

H.264

Audio Compression

G.711A

Recording Mode

Manual, Timing, Alarm, Motion detection

Search Mode

By time, event, channel, log

Backup Mode

Network download, USB backup

Video Input

4ch BNC

8ch BNC



Video Output

LCD:7 inch (Resolution:1024X768)

CVBS

VGA Resolution: 1280X1024

Audio Input

4ch RCA

4ch RCA



Audio Output

1ch RCA

Voice Talkback

1ch RCA

Live Video Resolution

PAL:720x576(D1 );NTSC:720x480(D1)

Playback Resolution

Relate on record resolution

Image Control

selectable

Remove Detection

Each channel can set independent detection zones and multilevel sensitivity

Video Display

1/4 multiple display

1/4/8 multiple display



Recording Frame Rate

PAL:25f/s(Adjustable)NTSC:30f/s(Adjustable)

Recording Storage

Local  HDD, Network

Local Playback

Select any 4 channel playback at same time

Alarm Input

4ch

4ch



Alarm Output

1ch output

PTZ Control

RS485

HD Interface

1 SATA Ports

Network Interface

RJ4510M/100M Adaptable Ethernet Connection

Mobile Phone View

Support  iPhone, blackberry, Windows Mobile, Android, Symbian

USB Interface

2 USB2.0 High-speed Port

Power Supply

12V 4A



DVR-7014KS 4 Channel CCTV DVR Kit H. 264 4x Outdoor Waterproof Night Vision IR Cameras





Camera specification:



Image Sensor
1/4" Color
Effective Pixels
NTSC: 648(H) x 488(V)
Lens Mount
3.6mm
Lens Angle
75°
Scanning System
2:1 Interlace
Number of IR LEDs
24 LEDs
Infrared Illumination
(Night Vision)
Visible up to 65' (20m)
Minimum Illumination
0 Lux (IR On)
Horizontal Resolution
420 TV-Lines
Synchronization System
Internal Synchronization
S/N Ratio
> 48dB
Gamma
0.45
Auto Gain Control
Built in
Power
12V DC
Operation Temperature
-18C ~ 43C /0F ~ 110 F
Back Light Compensation
Auto
Video Out
1.0V p-p 75 O BNC
Auto Iris
Video / DC





Package including:

4×IR CCD Camera
1×4CH H.264 DVR
1×4CH Power Distribution Wire
1×Special Camera Power
1×User^ s Manual and warranty card
1×IR Controller
4×18m BNC Wire
