SDI to HDMI converter KV-CV180(SDI to HDMI&VGA&AV multifunction converter ) excellence compatibility, best image quality and supporting wide signal formats.

KILOVIEW® KV-CV180 SD/HD/3G-SDI to HDMI &VGA & AV broadcast grade converter is a professional converter which supports various formats SD/HD/3G-SDI to HDMI&VGA&AV conversion.SDI to HDMI converter KV-CV180(SDI to HDMI&VGA&AV converter ) is compatible with SD SDI(270M),HD SDI(1.485G) and 3G SDI(2.97G) standard, built-in SDI re-clock circuit and circuit equalizer that can recover attenuation and distortion SDI signal after long-distance transmission. SDI to HDMI converter KV-CV180(SDI to HDMI&VGA&AV converter ) supports many image enhancement and handling technology such as color conditioning,3D denoise,interlacing/progressive video conversion,video amplification/scale,frame rate convert to guarantee image conversion meet professional quality standards

• Support any SDI input format;
• Support SMPTE 425M,SMPTE424M,SMPTE292M;

• With 1 CH SDI signal loopback;

• High quality 10bit YUV4:2:2 conversion, keeping color not distortion;
• Professional image enhancement, denoise, color conditioning, de-interlace and scaling;
• Support OSD and menu operation windows;
• Support HDMI DDC, self-adapt the best mode of HDMI/VGA;

• Support all above formats UP/DOWN interconversion; support Interlace/Progressive interconversion& f

• Blue screen warning when the signal loss;

• VGA specified output format: 720p/1080p;

• Embed SDI audio signal to HDMI signal automatically;

• Support AV(CVBS) signal output(PAL/NTSC standard optional);

• Support user to choose specified output format by remote-controller and set image output ratio.


Input interface :1×BNC SDI

Input signal type: SD-SDI(270Mbps),HD-SDI(1.485Gbps), 3G-SDI(2.97Gbps)

Support input format: 525i 59.94,625i 50       720p 23.98/24/25/29.97/30/50/59.94/60     1080i 50/59.94/60    1080p 23.98/24/25/29.97/30/50/59.94/60

SDI signal amplitude: 0.8Vp-p

SDI impedance: 75 Ohm

SDI coupling type: AC

SDI signal jitter(typical) :SD-SDI≤0.1UI HD-SDI≤0.2UI 3G-SDI≤0.4 UI

Maximum output coax length: Belden 1694A: SD-SDI 400m,HD-SDI 200m,3G-SDI 140m

Notice:transmission distance depends on source quality and coax specification. This parameter is the value that Phabrix SDI tester making signal and transmit through Belden 1694A coax. It may be different in practical application.

SDI loopback interface: 1×BNC SDI

HDMI output interface: 1×HDMI

AV(CVBS)output: 1×BNC

VGA output: 1×VGA

Frequency bandwidth: 165MHz/comply standard(HDMI 1.3)

Dimensions(mm): 156*100*36

Weight: N.W.: 340g G.W.: 695g

Operation temperature: -10°C ~ 60°C

Storage temperature: -30°C ~ 60°C

Relative humidity: 20~90% RH (Non-condensation)

Power supply: DC 12V, 1A

Relying on first-class R&D team, we have professional EPGA video processing technology, SDI signal processing technology and video compression and transmission technology.With the help of professional signal test instruments, we provide strictquality control for each product.
