Network to HD SDI 3G h.264 Decoder support RTP/ RTMP protocol

KV-DC101A   Network to HD SDI 3G h.264 Decoder support RTP/ RTMP protocol  is a network (IP) HD video decoder with high performance. KV-DC101A could get IP-Camera from network, stream media server or stream media on KV-EC serial encoder (based on RTSP, RTP or multicast, then outputs video and audio to SDI through self-adaptive decoding. KV-DC101A supports various output signals like SD(270M),HD(1.485G) standard, 525i, 625i, 720p, 1080i and 1080p(maximum 30Hz).

KV-DC101A   Network to HD SDI 3G h.264 Decoder support RTP/ RTMP protocol   has functions of self-adaptive decoding and intelligent controlling for network delay. Decoding delay could be lower or equal to 200ms in typical network environment. Even though low code rate decoding and about 10% network packet loss, KV-DC101 could use image enhancement and fault-tolerant technology to clearly restore encoding video and audio, no obvious distortion, smear, frame loss and mosaic phenomenon of pictures with features of actual color reproduction, clear sound and high fidelity. KV-DC101A supports H.264 encoding video with bit rate high up to 12Mbps and decoding output of AAC-LC/G.711 encoding video.

KV- DC101A   Network to HD SDI 3G h.264 Decoder support RTP/ RTMP protocol has image scaling capacity, could let after-decoding video larger/smaller converting to adapt to different output video format. Audio could be embedded in SDI signal, then synchronously transmitting with video, meanwhile transmitting Line Out analog audio.

Through cooperating with KV-EC serial encoder products, KV- DC101A also supports two-way voice intercom and RS-485 signaling pass-through function. KV- DC101A provides open source SDK, supporting Windows/Linux/Unix cross-platform and programming second development to realize manage and control for equipments.

  Network to HD SDI 3G h.264 Decoder support RTP/ RTMP protocol Features:

*Support SD/HD SDI interface, support AES/EBU embedded audio;

*Dual SDI output simultaneously (SDI distribution function), enhanced Cable Driver could guarantee that SD-SDI transmitting distance is longer or equal to 350 meters, while HD-SDI transmitting distance is longer or equal to 180 meters;

*Support various output formats like 1080p30/25/24, 1080i60/50,720p60/50, 480i/576i;

*Video scaling, frame rate conversion and image enhancement;

*Support RTP, RTSP and RTMP unicast/ multicast medial transmission protocol;

*Input and output of analog audio could realize two-way voice intercom, analog audio and SDI embedded audio could be transmitted synchronously;

*switching value input/output, connecting with sensor, alarm and other control equipment;

*RS-485 interface, could realize PTZ cloud control function, and two-way signaling pass-through with decoder/ PC port;

*Decoding delay is controlled by intelligent network, lower than 200ms in typical network environment;

*Image enhancement and fault-tolerant technology, strong resisting error code capability, excellent picture quality, clear acoustic;

*Provide communication protocol for software development SDK and device management control which can integrate seamlessly with the third party application platform.


   Network to HD SDI 3G h.264 Decoder support RTP/ RTMP protocol  Application Notes:

Parameter:

 Packing pictures:
