Brand: Dobry
Model: C168
Working frequency: 800/1900Mhz
Product name: CDMA wireless gateway FWT FCT fixed cellular terminal for IP PBX billing meter
Key words: dual band quad band LCD display CDMA gateway, CDMA fwt fixed wireless terminal, CDMA fixed cellular terminal, CDMA wireless voice box. CDMA sim box, CDMA call communicator for telephone, billing meter, alarm system and IP PABX, IP PBX etc.
Software version:
CDMA fwt fixed wireless terminal is a CDMA to Analog Converter (single port, insert 1 sim card only), the device can produce a FXS line
to allow a regular phone to be connected and used just like a local landline (PSTN) except your calls will go out
the CDMA network.
This device can both receive and make calls. Users can dial the local calls, domestic and international calls with
this Terminal connecting with a common wired desktop phone and a standard SIM card..
It is not a VOIP gateway, nor a CDMA +VOIP gateway; It is a CDMA Fixed Wireless Terminal that produces a Analog FXS phone line.
Application areas:
Remote country, Mountains, Dwelling house with weak signals, Public telephone shops
Offices, Removable places such as Ships, Trains, and Long distance buses.
The main applications:
Connect the RJ-11 FXS line to connect Ordinary telephone set for voice call.
Connect PBX for call extension.
Connect billing systems for public phone use.
Connect VoIP gateway to realize VoIP call termination.
Connect alarm system for security purpose. etc.
Features:
1) It is a 1 channel CDMA FWT/Gateway which has 2 RJ-11 outputs for extensions;
2)Ruim Support or Non-Ruim support (optional)
3) It can connect with ordinary telephone set, PBX , VOIP Gateway, Billing meter etc. ;
4) Dialing tone frequency:450hz;
5) Employ Industrial module to make;
6) SIM card supported (1.8V, 3V);
7) Caller ID display. Time and date display, the power supply of battery can display at the same time on the LCD.
8) DTMF Dialing;
9) Bell signal;
10) Polarity reversal;
11) Antenna socket (SMA);
12) Working status and Signal Strength by LED indicator;
13) Automatically connects to IP network when dialing long distance (optional)
14) Dial number Block (Optional)
15) Incoming number Block (Optional)
16) Volume adjustment. Time and date setting.
17) Auto card-locking and net-locking.
28) Back up Li-ion battery (Optional) 7.2V 750mAh.standby 24hrs, talking time: 2hrs.
Technical Specifications
1) Networks support: CDMA 800/1900MHZ.
CDMA800 1900MHZ
I) Transmission: 869 ~894MHz 1930 MHz ~ 1990 MHz
Ii) Reception: 824 ~849MHz 1850 MHz ~ 1910 MHz
3) Phone interface: supply RJ-11 Phone Interface
4) Hanging voltage: 45V
5) Picking off voltage: 30mA / 41mA
6) Dialing tone Frequency: 450Hz
7) Antenna interface: Antenna amplifying>2.5db
8) Sensitivity:<-104DBM
9) Transmitting power<3W
10) Color: White
11) AC-Adapter interface: Input: AC 110~240VAC 50~60Hz Output: 5DC 1A.
12) AC-Adapter type: EU,US,AU,British can be optional
13) Stand by hours: 24 Hours
14) Talk time: 2 Hours
15) Charging time: 6 hours
16) Power consumption:
Static≤25MA emission≤500MA
17) Peak power consumption: 0.25W/0.5W
18) Receive sensitivity: -104db
19) Antenna increment: All directions: 5.0db Certain/Selection: 12db
Operation Circumstance:
Operation temperature: -10c~60C
Storage temperature:-20C~70C
Operation humidity:45%-95%
Atmosphere pressure:86-106Kpa
Environment noise: <60DB
Transmitting Power:2W
Sensitivity: <-104dbm
Antenna Amplifying: >2.5db
Dialing frequency: 450Hz
Hanging voltage: 45V
Picking current: 30mA/41mA
Pictures:
item |
Quantity |
Remark |
CDMA FWT |
1pcs |
CDMA 800/1900MHZ |
Ac- adapter |
1pcs |
AC-110-240V, DC5V/1A |
Antenna |
1pcs |
Magnetic Antenna with 3m cable |
User's Manual |
1pcs |
English |
G.W: 0.5kg per set (including adapter, antenna and manual).
20pcs/CTN, 11KG/CTN, CTN Size: 42*38*26cm
1 year warranty
With R & D team, OEM is accepted in bulk order.
