Deluxe Full Height Turnstile
US$ 7,400 - 7,401
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Proud
Model Number:
FH2-2
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Double Routeway Full Height Turnstile for Office Building Access ControlUS$ 6,000 - 6,001MOQ: 1 Set -
Wing7-FLUS$ 30,000 - 45,000MOQ: 1 Piece
-
The SG1 is a Self-closing, Pedestrian Gate; CE, ISO9001US$ 800 - 801MOQ: 1 Pair
-
OPT1, Non Barrier Optical Turnstiles Provide a Perfect Combination of Security and Style.US$ 1,000 - 1,001MOQ: 1 Pair
-
OPT2 is an Optical Compact Elegant SecurityUS$ 900 - 901MOQ: 1 Pair
Place of Origin
Guangdong, China
Brand Name
Proud
Model Number
FH2-2
We attach great importance to perimeter protection on our premises. An intelligent fence system and automatic full-height turnstiles at all entrances mean we can respond with flexibility to the changing access control requirements of our company. Using an admission system we can control which of our 1200 members of staff are authorised to enter the premises-and when exactly they can do so. It is also easy to control access with bikes or goods carts thanks to special turnstiles.
Features
- Uses 30% less space than installation of two individual turnstiles
- Suitable for indoor or outdoor use
- Rotating section smoothly self-centers to the home position after every rotation
- Turnstile is made from welded assemblies, not bolted together components
- Easy to assemble
- High quality bearings and internal stainless steel cast components
- Splined connection between Top Channel and rotating section
- Easily integrates with any access control system
- Adjustable duration auto relocking if no passage after activation
- Optical rotation detection; no mechanical micro switches to break or adjust
- Manual key locks to unlock one or both turnstile rotation directions
- All finish types have stainless steel Top Channel covers
- Bearing covers hide exposed bolts
- Fail-lock entry / fail-safe exit; alternate configurations available
Options
- Integration of any size card reader
- Padded arm/heel protective sleeves
- A red / green or yellow / green / red array (user selectable) provides visual notification of turnstile and access system status
- Turnstile status lights - visual notification whether turnstile is open or closed to users
- Galvanized, powder coat, stainless steel, or powder coat over galvanized or stainless steel finishes
- Battery backup
- Additional channel weatherization and / or control board encasing
- Lock arm monitor (provides signal when lock arm(s) engaged)
- Out of service lock bracket (capability to padlock turnstile if out of service)
- Channel cover monitor (provides signal when channel cover removed)
- Remote key override
- Activation signal via serial communication (serial communication interface)
Technical Specs
- Height: 2324mm
- Width: 2400mm
- Depth: 1374mm
- Product Weight: 550kg
- Shipping Weight: 750kg
- Transformer: 220/110VAC, 50-60Hz.
- Power Requirements: Max power consumption is 130W per tandem turnstile with all available electrical options.
- Operational Voltage: 24VDC/5VDC
- Power Receptacles: The power junction box inside the Top Channel includes two 220/110VAC power receptacles providing a convenient way for installers or technicians to power tools or equipment used during installation and maintenance.
- Surge Protection: The turnstile controller uses a ceramic varistor for transient voltage suppression up to 80 amps for low voltage AC inputs. Control signal lines are protected by bi-directional transient voltage suppression diodes up to 600W per input. This combination provides superior lightning and surge protection.
- Bi-directional Solenoid Drivers: The turnstile controller provides one solenoid driver per rotation direction.
- Operation Temperature: -20F to 150F (-29C to 66C)
- Storage Temperature: -30F to 160F (-34C to 71C)
- Relative Humidity: 0-90% (non-condensing)
