Laboratory Fume Hood , Medical Equipments Used In Hospital

Product Name

Laboratory Fume Hood Medical Equipments Used In Hospital

Size

1200(W)*850(D)*2350(L) mm;

1500(W)*850(D)*2350(L) mm;

1800(W)*850(D)*2350 (L)  mm.

Color

Custom-made

Casework

1.2mm thickness of cold- rolled steel plate, after acid washing, phosphide and&nbs p;electrophoresis, sprayed with good quality anti- corrosion static coating.

Inside Lining

4mm thickness of Compact.

Worktop

1)19/20mm thickness EPOXY, Black Color

3)20mm thickness GRANITE ,

4)25mm thickness STAINLESS STEEL

5)19mm thickness WILSONART CHEMSURF/POSTFORMED MALAMINE (FORMICA) Black , Gray Color

6)20mm thickness CERAMIC, Black Color

Sash

Sash Handle

2mm Cold- rolled steel powered with epoxy coating.

Illumination

with not less than 300 Lux 30W fluorescent l amp set

Cup sink

Oval shaped PP Cup sink

Water Tap

Molded in one piece copper water tap, epoxy  powder coating surface with a ceramic valve.

Valve

1Water valve. (by custom)

Exhausting Duct

Anti-corrosion PP/PVC duct

Plinth

With 1.5mm thickness of cold- rolled steel plate, after acid washing, phosphide and ‘dian yong’, sprayed with good quality anti- corrosion static coating.

Technical specification

Noise: less than 60db  (International standard), Face velocity: 0.5m/s, 220V

Function

With an intelligent automatic delay protection device to exhaust residual corrosion air completely and pro long the service time of fume cupboard.

Socket

4 Electric sockets, (By custom)

Exhaust fan

not include exhausting duct &exhaust fan, will provide after receiving the detailed design of exhausti on duct.

China (Mainland)
