| WQD Factory Supply High Pressure Centrifugal Water Motor Filter Pump |
|
|
Operating Conditions:
1. Our pump is able to work normally and continually if the followng requirements are met.
2. Medium temperature:Not over +40°C
3. PH range of medium:4-10
4. Max. density of medium:1.2x103kg/m3
5.Viktage fkyctyatuib rabge:10% of rated voltage
6.Submersion depth: ≤ 5 meters
Motor:
1.Single phase
2.Insulation class:B
3.Protection:IP44
| Technical Data: | |||||||
| Model | Power |
Inlet (inch) |
Max.Flow (m³/h) |
H.Max (m) |
Packing Size (mm) |
G.W(kg) | |
| (kw) | (hp) | ||||||
WQD6-12 |
0.55 |
0.75 | 51 | 16 | 14 | 470-250*250 | 20.5/19 |
| WQD6-16 | 0.75 |
1.0 | 51 | 22 | 17.5 | 470*250*250 | 22.5/21 |
| WQD10-10 | 0.75 | 1.0 | 64 | 16 | 16 | 520*210*275 | 29/25 |
| WQD15-9 | 1.1 | 1.5 |
51 | 24 | 14.5 | 540*240*280 | 32/29 |
| WQD7-15 | 1.1 | 1.5 | 51 | 22 | 18 | 540*240*280 | 31/28 |
| Hydraulic Performance Curve |
| Work shop area | |||||||||
|
| BAQIU Company Introduction |
|
1)Taizhou BAQIU electrical and mechanical Co.,LTD which located in the home two of chinese water-Daxi, Wenling China.We are integratd manufactural factory. |
|
2)Our major productions are all kinds of water pumps.Based on excellent products and good reputation,they have won favorable views from customers both at home and aboard and passed some domestric. |
|
3)Our products are well sold in more than twenty province and cities in China,and exported to America,Europe, Australia and Southeast Asia etc. |
|
4)Quality always stands the first and honest is our concept.We provide reasonable price,punctuality and satisfying service.We sincerely welcome all the friends from the world to join in us and develop together. |
| More choices if you like ... | |||||||||
|
QB60
|
P-130 |
JET100L |
|||||||
|
QDX |
WQD
|
SWQD |
|||||||
PACKING: one pump one clour carton, two cartons in one big strong outside carton
SHPPING: 30 days after receiving the deposites or original L/C
| Shipping & Payment |
| 1.FedEx/DHL/UPS/TNT for samples |
| 2.Batch goods delivered by sea |
| 3.Customers specifying freight forwarders or negotiable shipping methods |
| 4.Delivery Time:7-15 days for samples; 25-30 days for batch goods |
| 5.30%T/T or 100%LC,balance against the copy of B/L |
“Quality always stands the first” and “Honest” is our concept. we provide reasonable price, punctuality delivery and satisfying service
1)Q: Are you a factory or a trading company?
A: Pump manufacturer.
2) Q: What is your MOQ of this item?
A: 100PCS.
3)Q: How many times for one container production?
A: 30days after receiving the depoistes,40 days in very busy season.
4)Q: How about your quality?
A: We arrang the prodcution quality according to customers' request.
5)Q: What are your payment terms?
A: 30% t/t deposit and the balance t/t against copy of BL.
6)Q: What is your company's available production capacity?
A: 20000 per month.
7)Q: How about the packing of this model?
A: Standard export strong colour carton.
| 1. Please tell us some detail information, such as the Capacity, Head, Medium, Voltage etc. |
| 2. We can recommend pumps for you according to your requirements as well. |
| 3. If you have the certificate requirements, please let me know. |
| 4. We will make quotation for you. After your confirmation, PI will send to you. |
| 5. We will arrange the order for you as soon as receiving your payment. |
| 6. After the goods finished, we will send the goods to you. |
| 7. Note: Customers can order all product samples we put or you can also have your own idea, as we are custom-made product supplier, so any change of goods are available. |
