12v 60 Watt Lightweight Solar Charger-thin Solar Panel

Name: 12v 60 Watt Lightweight Solar Charger-thin Solar Panel
Brand: ocean
SKU: 123311395

US$ 2.2 - 2.5 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ocean

Model Number:

SYK60-18MFX

Guangzhou Ocean Solar Power Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB GuangZhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ocean

Model Number SYK60-18MFX

Material Monocrystalline Silicon

Size 905*570*2.5mm

Number of Cells 36 pcs

Max. Power 60w

Specifications

12 Volt DC17.3 volts peak power
3.33Amps output
4 perimeter holes allow versatile mount applications
5 foot of output cable

Advantages of the 12v 60 Watt Lightweight Solar Charger for boat ,RV,yartch :

1-High stability through Aluminium back plate.

2-Flexible and bendable plate for various installations (max. 3%) by innovative chaining technology.

Surface can be walked on.

3-Highest efficiency crystalline cells

4-Seawater resistant, highly transparent, self-cleaning EVA-foil (Teflon coated)

5-Small, robust, flat, sealed connection box. simple to connect. Screwed and/or glued. Allows safe

contact and prevents damage even in extreme marine conditions 1.5 m cable included.

6-Easy installation, glue or silicone with optional screw holes.

1. 60 Watt Thin Solar Battery ChargerElectrical Technical Data
Model NO	*SYK60-18MFX*
Peak Power (Pmax)	(W):	60
Production Tolerance	(%):	±3
Maximum Power Voltage (Vmp)	(V):	18
Maximum Power Current (Imp)	(A):	3.33
Open Circuit Voltage (Voc)	(V):	21.24
Short Circuit Current (Isc)	(A):	3.67
Maximum System Voltage	(VDC):	1000
Solar Cell Type	Mono
Solar Cell Efficiency	16.8%
2. 60 Watt Thin Solar Battery Charger Size&Packing
Length	905mm
Width	570mm
Depth	2.5mm
N.W Per Piece	2KGS(4.4LBS)
Master Carton Size (5PC/CTN)	*980645200MM*
G.W/CTN	18.55KGS
