Stable Fleet Cars Vehicle GPS Tracker M528 With Easy Installation

Stable Fleet Cars Vehicle GPS Tracker M528 With Easy Installation thumbnail-1
Stable Fleet Cars Vehicle GPS Tracker M528 With Easy Installation photo-1
Negotiable MOQ: 100 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, Gps Tracker, GSM
Use:
Automotive
Screen Size:
Other
Contact Supplier Request Quote Chat Now
Shenzhen Gator Communication Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, Gps Tracker, GSM
Use Automotive
Screen Size Other
Function Other
Place of Origin Guangdong, China
Brand Name Gator
Model Number M528

Specifications

Stolen vehicle tracking M528 multi-functional and stable with competitive price and CE, ISO9001 certificate, with relay

Fleet/Logistics Management GPS Tracking:M528 With SOS/Geo-fence Alarm



Stable Fleet Cars Vehicle GPS Tracker M528 With Easy Installation

++Easy installation
++Confirmed stable performance

++Advantageous market competitiveness



++. 3-year warranty

++. Real time tracking 24/7 over PC/Smart phone/Tablet. So the targets will be under your eyes all day long

++. Monitor Fuel with a fuel sensor. Or monitor temperature for food storage trucks

++. Disable/Enable engine remotely. Or close the doors remotely

++. Listen-in/Voice monitoring---Dial the SIM card number, and you can hear everything over the target

++. Anti-theft alarm for illegal door opening and illegal engine start

++. Detect ACC, engine, doors, air-conditioner

++. AGPS location for signal dead zone

++. Overspeed/Harsh Braking alarm

++. Parking/Moving alarm

++. SOS/Geo-fence alarm

++. Fatigue driving alarm

++. Power-cut alarm

++. High and low voltage alarm

++. Flexible customization of both hardware and software

++. Multi-language localization, currently 19 languages are supported

++. History playback in animation. You can view the past routes for as long long as a year

++. Run various system reports, like history report, alarm report, mileage report, etc

++. GPS and GSM based, Support ODM for CDMA/WCDMA Protocols

++. Track by SMS which replies the location, and a URL linking to google map

++. Track by GPRS that transmits data and remote control command between the device and the platform

++. Track by Time Interval, or on demand by roll call

++. Record mileage, speed etc

++. Remote monitoring by authorization

++. High/low-level output voltage measuring

++. Record data logging function

++. Remotely lock vehicle

++. Internal flash memory 16MB to store 30000 points data. So when the M528 is disconnected to the system (for example, the GPRS signal is weak), location data will be stored in the flash memory. Data will be uploaded to the server once the tracker is reconnected to the system (the GPRS signal is ok).

++. Rremote update of firmware

++. Support TCP/UDP



Physical Parameters:

Dimension

101mm*50mm*24mm

G.W

0.5KG

Exterior Power Supply

DC8V-60V

Inner Lithium battery

Last more than 4 hours

Communication protocol

UDP/TCP

GPS Sensitivity

-159dBm

GPS frequency

L1,1585.42MHZ

C/A coding

1.023 MHz chip rate

routeway

20

Default data

WGS-84

Height restriction

6000 feet

Speed restriction

1000 knots

Acceleration restriction

Less than 4g

Exterior GSM antenna

Receive GSM Signal better

Exterior GPS antenna

Receive GPS signal better

Power Consumption

Active mode(avg.)50mA-160mA

when exterior voltage is 12V

Sleep mode <20mA

Operating Temperature Range

-20°C to +70°C

Humidity

Up to 95% non-condensing

position accuracy

10-metres,2D RMS

GSM chip

Support Quad-band(850/900/1800/1900 MHz)

GPS chip

U-blox (super sensitivity and high accuracy)

Hot start

1 sec., average

Expansion of peripheral

Three peripherals(handle/camera/ scheduling screen)

LED light

Red:power-on state,yellow:communication module state,green:GPS module working state
