We are factory that mainly produce JYSL brand 6Ton to 55Ton amphibious excavator by assembling different brands and model excavator upper parts, like PC200, HITACHI ZX210, DH215, EX120,SH120.... Also, if you have crawler excavator, we can only produce JYFT brand amphibious undercarriage (steel pontoon) for you. Sincerely wish could have chances to do businss with you and welcome you to visit our factory!
Introduction of JYSL brand amphibious excavator:
A: Drives:
The amphibious excavator undercarriage (Pontoon) can be 2WD or 4WD by assembling 2 or 4 DOOSAN brand travel motor assemblies. Good designed pontoon shape and structure make the pontoon moving so good and fluently.
B: Chains:
Considering the machine reliablity and safety, we assemble 3 rows of chains on each pontoon. Heavy duty chains are made of special produced 40Cr steel. Chains life will be longer than common steel chains.
C: Applications:
1.Deepening of canal, river channel and river mouth
2.Swamp land clearing at mining area, plantation and forest
3.Building bund for flood prevention and land reclamation
4.Building bund wall for fish and shimp ponds and salt making industry
5.Sludge clearing of lakes, ponds and water reservoir
6.Digging trenches for oil and gas piping installation
7.Transporting and clearing landslide and flood hit area
8.Swamps and wetlands construction
9.Road construction through wetlands.
TECHNICAL PERFORMANCE AND SPECIFICATION OF JYSL-350-3
| Engine | Engine model | Cummins 6BTA-5.9 ( Isuzu 6BG1TRP ) | |||
| Fuel | Diesel | ||||
| Number of Cylinders | 6 | ||||
| Number of strokes | 4 | ||||
| Capacity | 5.9L ( 6.494L) | ||||
| Power | 112KW (120KW) | ||||
| Turbo charged | YES | ||||
| Water-cooled | YES | ||||
| Fuel tank | 410L | ||||
| Hydraulic System | Flow rate of pump | 2 X 212 L / min | |||
| Circuit of working devices | 35000KP | ||||
| Circuit of walking | 35000KP | ||||
| Circuit of turning | 28000KP | ||||
| Swing speed | 12 rpm | ||||
| Hydraulic pump model | KPM K3V112DT | ||||
| Control valve model | Parker AV-280 | ||||
| Swing motor model | SUNJIN K250D | ||||
| Travel motor model | ETON JMV-147 | ||||
| Opeating Datas | Operating Weight | 35000KG | |||
| Maximum Tractive effort | 205KN | ||||
| Arm size | 16 Meter long reach arm | ||||
| Bucket capacity | 0.5M3 | ||||
| Walking speed | 7 KM / H (on land and swamp) 9 KM / H (on deep water) | ||||
| Max.Working depth (on water) | 2.5 Meter (not assembling stabilizers) 6.5 Meter (by assembling stabilizers) | ||||
Model |
Max. Digging Radius (M) |
Max. Digging Depth (M) |
Max. Digging Height (M) |
Max.Dumping Height (M) |
|
JYSL-350-1 (with standard arm and 1.0M3 bucket) |
9.1 |
5.71 |
9.89 |
7.09 |
|
JYSL-350-2 (with 2M longer arm and 1.0 M3 bucket) |
10.99 |
7.7 |
11.04 |
8.7 |
|
JYSL-350-3 (with 16M long arm and 0.5M3 bucket) |
15.6 |
10.6 |
15.3 |
13.2 |
Dimensions ( JYSL-350-3 ) |
mm |
|||
A |
Track length |
10000 |
||
B |
Ground contact length of tracks |
6600 |
||
C |
Tail swing radius |
2750 |
||
D |
Overall length |
14500 |
||
E |
Overall height (to the top of arm) |
3880 |
||
F |
Ground clearance of counter weight |
2025 |
||
H |
Overall width |
4940 |
||
I |
Track gauge |
3440 |
||
J |
Track width |
1500 |
||
K |
Ground clearance |
1140 |
||
L |
Track height |
1840 |
||
M |
Overall height (to the top of cab) |
3870 |
||
N |
Width of the top part |
2710 |
||
WORK PERFORMANCE
(JYSL-350-1 with standard arm and 1.0M3 bucket)
(JYSL-350-3 with 16M--18M long arm and 0.5CBM bucket )
( PRODUCTION WORKSHOP )
