Needle Roller / Ball Thrust Combination: Of a non separable design has a cover attached to the housing washer which extends over the needle roller bearing outer ring, these are particularly suited to grease lubrication as the cover acts to retain the lubricant. They are able to support heavy single direction thrust loads in addition to radial loads, they also permit relatively high speed operation.
Benefits: High speed / thrust loading, grease lubrication, non separable - easily mounted
NKX series
NKX series needle roller / thrust ball bearings do not have a cover around the thrust ball bearing. As a result, both the ball and cage assembly and shaft washer can be mounted separately from the rest of the bearing.
NKX .. Z series
NKX .. Z series needle roller / thrust ball bearings are non-separable. They have a stamped steel cover that extends over the shaft washer of the thrust ball bearing. It is firmly attached to the housing washer that is integral to the needle roller bearing outer ring. The cover makes these bearings non-separable. We supplies the thrust ball bearing in this series filled, as standard, with a high-quality grease that has good rust inhibiting properties. The cover, which has no lubrication holes, forms a gap-type seal with the shaft washer to retain the grease in the bearing.
Lubrication:
For lubrication, the outer ring has a lubrication groove and lubrication holes. NX and NKX are lubricated with oil. The end cap in NX has lubrication holes. NX..-Z and NKX..-Z are lubricated with grease. The axial bearing component is greased using a lithium complex soap grease to GA08. The end caps do not have lubrication holes.
Other series:
Needle roller/angular contact ball bearings
Needle roller/axial ball bearings
Needle roller/axial cylindrical roller bearings
Axial/radial roller bearings
Axial conical thrust cage needle roller bearings
Crossed roller bearings
