Tri-axle Low Bed Semi Trailer 40TON
- Qingdao Shanghai
- T/T D/P D/A
You May Like
-
CHENGLI 6x4 WATER TANK TRUCK
-
Dump Truck ZZ3257M3447A1 Standard Dump Truck Dimensions and Lift Axle for Dump Truck
-
Chinese Most Popular Dump Trucks!6x4 Beiben Dump Trucks for Sale V3
-
HOWO Dump Truck ZZ3257M3447A1 and Dump Truck Spare Parts:dump Truck Lift Hydraulic Cylinder
-
GOLDEN PRINCE WATER TANK TRUCK 4*2
-
6x4 New Garbage Truck
Product Details
| Type | Semi-Trailer | Material | Steel | |
| Certification | Other, ISO,3C | Size | 13000*3000*2015mm | |
| Max Payload | 40TON | Place of Origin | Shandong, China | |
| Brand Name | HUAYU | Model Number | LHX9404 |
Product Description
Specifications
tri-axle low bed semi trailer 40TONused low bed trailer
hydraulic low bed trailer
tri-axle low bed semi trailer
Tri-axle low bed semi trailer 40TON
DIMENSIONS |
| ||||||||||||
Tare weight | 11000kg | Payload | 40000 kg | ||||||||||
Overall length | 13000mm | Overall width | 3000mm | Overall height | 2015mm | ||||||||
SPECIFICATION | |||||||||||||
Chassis | Heavy duty and extra durability designed I beam;opting for high tensile steel Q345,welded by automatic submerged-Aac plate 16mm.bottom plate 18mm.middle plate 10mm.height 500mm | ||||||||||||
Axle | Number | 3 | Brand | Fuwa | Capacity | 13T | |||||||
Suspension | Mechanical suspension |
| |||||||||||
Leaf spring | Leaf spring | ||||||||||||
Floor | 5mm checkered plate | ||||||||||||
Tire | 12R22.5 12 pcs | ||||||||||||
Wheel rim | 9.0 | ||||||||||||
Kingpin | 3.5 bolt-in king pin |
| |||||||||||
Landing gear | two-speed,manual operating ,heavy duty landing gear 28t | ||||||||||||
Ladder | Mechanical ladder | ||||||||||||
Vehicular applications | Machine transport | ||||||||||||
Drawing | Including |
| |||||||||||
Braking system | RE6 relay valve ;T30/30 spring brake chamber;40L air tanks | ||||||||||||
Paiting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint | ||||||||||||
Accessories | One standard tool box | ||||||||||||
