Chinese Forklift Battery YTO CPD25 Electric Forklift, New Forklift Price
chinese forklift battery YTO CPD25 electric forklift, new forklift price
| |||||||||||||||
| Speciality parameter | Model | Unit | CPD25 | ||||||||||||
| Power type | Battery | ||||||||||||||
| Rated capacity | kg | 2500 | |||||||||||||
| Load center | d | mm | 500 | ||||||||||||
| Lift height | h2 | mm | 3000 | ||||||||||||
| (/)Mast tilt angle (forward/backward) | α/β | Deg | 6/12 | ||||||||||||
| Wheel-base | L4 | mm | 1500 | ||||||||||||
| (/)Tread(front/rear) | b4/b5 | mm | 970/950 | ||||||||||||
| Performance parameter | Travel brake | -Hydraulic-Foot pedal | |||||||||||||
| Parking brake | -Mechanical-Hand level | ||||||||||||||
| ()Lift speed(with load) | mm/s | 260 | |||||||||||||
| (/)Lower speed (with/without load) | mm/s | (with load)<600 ,(without load)>300 | |||||||||||||
| ()Travel speed (without load) | km/h | 12 | |||||||||||||
| ()Max. gradeability (with load) | % | 10 | |||||||||||||
| (/)Max. Towing (with/without load) | kN | 9.8/8 | |||||||||||||
| (/)Weight Distribution with load(front/rear) | 5900/840 | ||||||||||||||
| (/)Weight Distribution without load(front/rear) | 1825/2415 | ||||||||||||||
|
Power, transmission and others |
Motor | Driving Motor | Model | XQ-6.3-1T | |||||||||||
| Rated power | kw | 6.3 | |||||||||||||
| Rated rotation | r/min | 1200 | |||||||||||||
| Woring Motor | Model | XQD-8.6-C | |||||||||||||
| Rated power | kw | 8.6 | |||||||||||||
| Rated rotation | r/min | 1550 | |||||||||||||
| Controller | Manufacturer | CURTIS | |||||||||||||
| Type | MOSFET | ||||||||||||||
| Battery | Voltage | V | 48 | ||||||||||||
| Capacity | Ah | 360 | |||||||||||||
| Size(L×W×H) | 820×1065×520 | ||||||||||||||
| Gearbox | Transmission type | Mechanical | |||||||||||||
| Tire | type | Pneumatic tyre | |||||||||||||
| Model | Front | 7.00-12-12PR | |||||||||||||
| Rear | 18×7-8-14PR | ||||||||||||||
| Others | Dead weight | kg | 4240 | ||||||||||||
| Free lift height | h4 | mm | 140 | ||||||||||||
| Fork | ×× Thickness×Width×Length | c×b×a | mm | 40×125×1070 | |||||||||||
|
Overall dimensions |
()Overall length(without forks) | L2 | mm | 2430 | |||||||||||
| Overall width | b1 | mm | 1150 | ||||||||||||
|
Overall height |
Extended height(mast) | h1 | mm | 4030 | |||||||||||
| Lower height(mast) | h3 | mm | 1995 | ||||||||||||
| Overhead guard | h7 | mm | 2150 | ||||||||||||
| Min. turning radius | Wa | mm | 2100 | ||||||||||||
|
Min. under ground clearance |
Under mast | m1 | mm | 110 | |||||||||||
| Center of wheel-base | |||||||||||||||
