Home > Products > Logistics Machinery > HUAHE 2000KG mini forklift HH20Z
HUAHE 2000KG mini forklift HH20Z
- 300 Unit / Units per Month
- Shanghai Lianyungang Shenzhen
- T/T Credit Card
Product Details
| Condition: | New | Place of Origin: | Zhejiang, China | Brand Name: | HUAHE |
| Model Number: | HH20Z | Type: | Manual Pallet Truck | Power Souce: | Diesel Engine |
| Rated Loading Capacity: | 2000kg | Max. Lifting Height: | 3-6M | Min. Lifting Height: | 100mm |
| Fork Length: | 1070mm | Fork Width: | 125mm | Overall Dimensions: | 3750*1225*2090mm |
| Certification: | 3C,CE,ISO,CNAS,TUV | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
HUAHE 2000KG mini forklift HH20Z
Engine: A495 Engine(Motor)
More powerful
Tires: Pneumatic Tire-Cheng Shin Tire
Generals | Model | Unit | HH20 | HH20Z | |
Power type |
| Diesel | |||
Rated capacity | Kg | 2000 | |||
Load center | mm | 500 | |||
Dimensions | Lift height | mm | 3000 | ||
Free lift height | mm | 130 | |||
Fork size (L×W×T) | mm | 1070×122×40 | |||
Mast inclination F/R | Deg | 6°/12° | |||
Front overhang | mm | 482 | |||
Overall Dimensions | Length to face of fork | mm | 2480 | ||
Overall width | mm | 1150 | |||
Mast lowered height | mm | 2095 | |||
Overhead guard height | mm | 2120 | |||
Turning radius | mm | 2320 | |||
Min. right angle aisle width | mm | 1910 | |||
Performance | Travel speed | Unload I/II | Km/h | 9/20 | |
Full load I/II | Km/h | 8.8/18.5 | |||
Lift speed | mm/s | 480 | |||
Max. grade ability | % | 20 | |||
Max. drawbar pull | Kn | 14 | |||
Self weight | Kg | 3720 | |||
Wheels & Tires | Tires | Front |
| 7.00-12-12PR | |
Rear |
| 6.00-9-10PR | |||
Tread | Front Q | mm | 970 | ||
Rear S | mm | 970 | |||
Wheelbase | mm | 1650 | |||
Min. ground clearance (unload/full load) | Mast | mm | 152/132 | ||
Frame | mm | 158/138 | |||
Drive units & Control | Battery | V/Ah | 12/90 | ||
Engine | Model |
| C240 A495BPG | ||
Rated output | Kw/rpm | 34.5/2500 39/2650 | |||
Rated torque | N.m/rpm | 139/1800 168/1800 | |||
Displacement | cc | 3059 2980 | |||
Transmission | Type |
| Hydraulic | ||
Shift Fwd/Rwd |
| 1/1 Power shift | |||
Operating pressure | Mpa | 17.5 | |||
