seamless steel tube API linepipe sch40/sch80
1.OD:21.3-610MM WT:3-120mm
2.Standard:API 5L,API 5CT,ASTM A106,ASTM A53, GB/T8162,GB/T8163,GB/T5310,GB/T3087,GB18248
3.Steel Grade:GrA,GrB,X42-X70,Q345B,ST37,ST37.2,10#,20#,J5,K55,N80,L80,T95,C95,P110,Q125
4.Length:Single random, double random OR fix length 3-13m
5.Origin:China
6.Surface Finishes:Bare , oiled, mill varnish, galv., FBE,FBE Dual, 3LPE, 3HPE,3LPP,Coal Tar Epoxy,Concrete Coating and Tape Wrap, Bitumen Coating as per customer's request.
7.End finishes: Plain end or beveled ends, Threaded & Coupled
2) By plastic bag then strips;
3) As client' requirements.
Shipping: We will delivery asap.about 25 days to finish a 500 tons order if without stock
seamless steel tube API linepipe sch40/sch80
Q1: Could you tell me your loading port ?
A: Our factory is 470km away from Qingdao port ,China
and 400km away from Tianjin port,China.
but to save the domestic charges,we always choose Qingdao port to export.
Q2:Could you supply Mill Test Certificate?
A: Yes.We can. we can supply MTC, API 5L, API 5CT, ISO,Certificate of Origin
If your order need the inspetion by third party such as SGS,it is no problem.
Q3:Payment Terms?
A: We can accept T/T,D/P ,L/C,D/A.
But we need your 30% deposit to engine the production.
Grade and Chemical Composition:
| Grade | C≤ | Mn | P≤ | S≤ | Si≥ | Cr≤ | Cu≤ | Mo≤ | Ni≤ | V≤ |
| A | 0.25 | 0.27-0.93 | 0.035 | 0.035 | 0.1 | 0.4 | 0.4 | 0.15 | 0.4 | 0.08 |
| B | 0.3 | 0.29-1.06 | 0.035 | 0.035 | 0.1 | 0.4 | 0.4 | 0.15 | 0.4 | 0.08 |
| C | 0.35 | 0.29-1.06 | 0.035 | 0.035 | 0.1 | 0.4 | 0.4 | 0.15 | 0.4 | 0.08 |
Mechanical Properties:
| Grade | Rm Mpa Tensile Strengh | Mpa Yield Paint | Eongation | Delivery Condition |
| A | ≥330 | ≥205 | 20 | Annealed |
| B | ≥415 | ≥240 | 20 | Annealed |
| C | ≥485 | ≥275 | 20 | Annealed |
Diamension Tolerances:
| Pipe Type | pipe sizes | Tolerances | |
| cold drawn | ≤48.3 | +/- 0.4mm | OD |
| cold drawn and hot rolled | ≥60.3 | +/- 1% | OD |
| cold drawn and hot rolled | +/-12.5% | WT |
Annealed , Bright annealed , Spheroidize annealed, Normalized , Stress relieved, Cold finished, Quenched and Tempered
Test:
Chemical Analysis, Mechanical Properties ( Ultimate Tensile Strength, Yield Strength, Elongation), Technical Properties (Flattening Test, Bending Test,Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray test, NDT Test.).
seamless steel tube API linepipe sch40/sch80
Liaocheng Xinpengyuan Metal Manufacturing Co.,Ltd
Add:FengHuang Industry Garden, Liaocheng,Shandong Province,China
Tax ID:372500774181722
Mobile:15966276872
Tel: 86-635-8577600 Fax:86-635-8570577
E-mail:angela at
Skype:angelashandong
Website on :http://lcxinpeng.en.
