Mini Multi-function Excavator/Small Excavator XE215C for Sale
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
XCMG Excavator
Model Number:
XE215C Excavator
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Lianyungang Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Xcmg Wheel Loader Zl50gn Compact Wheel LoaderUS$ 1 - 40,000MOQ: 1 Set -
CHANGLIN ZL40H Wheel LoaderUS$ 10,000 - 50,000MOQ: 1 Set
-
Popular Brand Mini Wheel Loader ZL50G With Famous EngineUS$ 10,000 - 50,000MOQ: 1 Set
-
6 Ton XCMG Wheel Loader Front End Loader LW600KUS$ 40,000 - 100,000MOQ: 1 Unit
-
3ton XCMG LW300F Wheel LoaderUS$ 30,000 - 50,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
XCMG Excavator
Model Number
XE215C Excavator
Condition
New
Moving Type
Crawler Excavator
Operating Weight
21450kg
Bucket capacity
0.8~1.0m³
Maximum Digging Height
9640MM
Maximum Digging Depth
6655MM
Machine Weight
21450kg
Max Digging Radius
9925MM
Rated Speed
106.5/1950kw/rpm
Certification
ISO,CE
After-sales Service Provided
Engineers available to service machinery overseas
Welcome to Oriemac!
As authorized dealer,we specialize in exporting full kinds of excavatormade by Chinese famous factory,including XCMG,SDLGCHANGLIN,FOTON,LIUGONG,CHENGGONG.
Our company will offer you the best quality products with reasonable
price,quick delivery,and professional after-sale service.
Please don’t hesitate to let us know if you have any questions about
the products.Your reply would be highly appreciated.
Contact Person:Betty Ding
Skype: dgongzuo
Mobile: +86-182-2104-5926
Mini multi-function excavator/Small excavator XE215C for sale:
| Model | Unit | XE215C | |
|---|---|---|---|
| Operating weight | kg | 21450 | |
| Standard bucket capacity | m³ | 0.8~1.0 | |
| Engine | Engine Model | / | BB-6BG1TRP |
| Direct injection | / | √ | |
| Four strokes | / | √ | |
| Water cooling | / | √ | |
| Turbo charged | / | √ | |
| Air to air intercooler | / | × | |
| No. of cylinders | / | 6 | |
| Rated power/speed | kw/rpm | 106.5/1950 | |
| Max. torque/speed | N.m | 551/1600 | |
| Displacement | L | 6.494 | |
| The main performance | Travel speed | km/h | 5.5/3.3 |
| Swing speed | r/min | 13.3 | |
| Max. gradeability | / | ≥35 | |
| Ground pressure | kPa | 45.5 | |
| Max.Bucket digging force | kN | 138 | |
| Max.arm crowd force | kN | 103 | |
| Max.traction force | kN | 184 | |
| Hydraulic system | Main pump | / | 2 Plunger pump |
| Rate flow of main pump | L/min | 2×206 | |
| Max pressure of prime relief valve | MPa | 31.5/34.4 | |
| Max pressure of travel system | MPa | 34.3 | |
| Max pressure of swing system | MPa | 28 | |
| Max pressure of pilot system | MPa | 3.9 | |
| Oil capacity | Fuel tank capacity | L | 360 |
| Hydraulic tank capacity | L | 220 | |
| Engine lubrication | L | 25 | |
| Overall dimensions | A Overall length | 9525MM | |
| B Overall width | 2990MM | ||
| C Overall height | 3000MM | ||
| D Overall width of upperstructure | 2710MM | ||
| E Track length | 4270MM | ||
| F Overall width of undercarriage | 2990MM | ||
| G Crawer width | 600MM | ||
| H Track length on ground | 3462MM | ||
| I Crawer gauge | 2390MM | ||
| J Clearance under counter weight | 1050MM | ||
| K Ground clearance | 470MM | ||
| L Min.tail swing radius | 2750MM | ||
| Working range | A Max. digging height | 9640MM | |
| B Max. dumping height | 6800MM | ||
| C Max. digging depth | 6655MM | ||
| D 8inch horizonal digging depth | 6470MM | ||
| E Max. vertical wall digging depth | 5695MM | ||
| F Max. digging reach | 9925MM | ||
| G Min. swing radius | 3530MM | ||
| Angle of arm deflection | Degree | ||
