Specifications
yokogawa temperature transmitteryokogawa temperature transmitter eja series
Brand new, One year warrenty!
Best price , Fastest delivery!
Origin of Country is Japan, made in Japan!
The Yokogawa Pressure Transmitter EJA range is Yokogawa’s most successful pressure transmitter. First released in 1991, it continues to offer high performance and high reliability for almost any application. With an installed base of over 4-1/2 million EJA-A transmitters worldwide, it has a proven track record of exceptional mean-time-between-failure that is unmatched in the industry.
The Yokogawa Pressure Transmitter EJX range of transmitters is Yokogawa’s premium performance line of DPharp pressure transmitters. Released in 2004, it offers the most technologically advanced solution with class-leading performance and stability specifications. Additionally, the EJX family offers unique features such as standard IEC61508 certification, optional contact output, advanced diagnostics, multivariable mass flow measurement and ISA100 wireless capability.
EJA110A Differential Pressure Transmitter |
|||||
L Capsule |
M Capsule |
H Capsule |
V Capsule |
||
Range |
-10 to 10 kPa |
-100 to 100 kPa |
-500 to 500 kPa |
-0.5 to 14 MPa |
|
Span |
0.5 to 10 kPa |
1 to 100 kPa |
5 to 500 kPa |
0.14 to 14 MPa |
|
Accuracy |
±0.075% |
±0.065% |
±0.065% |
±0.065% |
|
Degrees of protection |
IP67, NEMA 4X, and JIS C0920 immersion proof |
||||
Certificates |
FM, CENELEC ATEX, CSA, IECEx |
||||
Output |
4 to 20 mA DC, FOUNDATION™ fieldbus or PROFIBUS PA 2-wire system with digital communication |
||||
Supply voltage |
BRAIN and HART:10.5 to 42 V DC (10.5 to 30 V DC for Intrinsically safe type) |
||||
Ambient temperature |
-40 to 85 deg C (-40 to 185 deg F) (general use type) |
||||
Process temperature |
-40 to 120 deg C (-40 to 248 deg F) (general use type) |
||||
Maximum working pressure |
16MPa(2300psi) |
||||
Mounting |
2-inch pipe mounting |
||||
Wetted parts material |
Capsule |
SUS316L(Diaphragm material is Hastelloy C-276), |
|||
Cover flange |
SUS316, Hastelloy C-276, Monel |
||||
Housing |
Cast aluminum alloy or SUS316 equivalent stainless steel (optional) |
||||
We supply the following YOKOGAWA Transmitter:
1> EJA110A
2> EJA120A
3> EJA130A
4> EJA210A/220A
5> EJA310A
6> EJA430A.
7> EJA440A
8> EJA510A/EJA530A
9> EJA118
10> EJA438
11> EJA115
12> EJA213
Send Inquiry to This Supplier
