SC100/200 Construction Elevator, Buliding Elevator With CE,ISO Certification

FOB Price

US$ 1 - 100,000 / Set

1 Set(Min. Order)

Port China main port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	YU JIE	Model Number	SC100
Usage	Construction Hoist	Power Source	Electric
Sling Type	Chain	Maximum Lifting Weight	1T per cage construction hoist
Maximum Lifting Height	200m	Lift Speed	36m/min
Certification	ISO/CE	Warranty	15 months after delivery from factory
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

SC100/200 Construction Elevator, Buliding elevator with CE,ISO certification

SC100 Construction Elevator adopted computer aided design. Comparing with traditional construction hoists, it is attractive, light, easy to handle, secure, applicable, and popular.

Depending on special needs of regular or irregular sections, the lifting capacity can reach up to 1~2 tons, and the running speed can reach 28~38m/min. Moreover, VVVF speed regulation and PLC enable 0~68 limitless speed, automatic layer selecting and leveling as required.

SC100 Construction Hoist is excellent in technical performance, more secure in operating mechanism, and more compact in structure.

Features :

1. Energy, starting current is less than the rated current.

2. Speed adjustable up to enhance the speed of 63m/min.

3. Frequency control system

4. Kai brake smooth, low mechanical wear and tear.

5. Use of domestic first-class"SSS"three drive-powered body.

6. Antidropping device is for the Shanghai Construction ASTRI40type automatic braking when falling

7. Drive motor, reducer double safety insurance, fastening frame, more secure and reliable.

Main Technical Parameters

Parameter	Unit	Model
Parameter	Unit	SC100	SC100/100	SC200	SC200/200
Rated capacity	kg	1000	2×1000	2000	2×2000
Number of people	No.	12	2×12	16	2×16
Rated lifting speed	m/min	36	36	36	36
Max.lifting height	m	200	200	200	200
Motor power	kw	2×11	2×2×11	3×11	2×3×11
Suspension cage inner size	m	3×1.3×2.2	3×1.3×2.2	3×1.3×2.2	3×1.3×2.2
Weight of 650 standard section	kg	124	148	124	148
Dimension of 650 standard section	mm	650×650×1508	650×650×1508	650×650×1508	650×650×1508
counter weight	kg	=	=	=	=
Suspender loading capacity	kg	200	200	200	200
Dimension of 800 standard section	mm	800×800×1508	800×800×1508	800×800×1508	800×800×1508
