poultry farm maize silo for sale

Name: poultry farm maize silo for sale
Brand: BODA
Price: USD $1,000 - 100,000 / Set

FOB Price

USD $1,000 - $100,000 / Set

1 Set(Min.Order)

Supply Ability 1500 Set / Sets per Month
Port QINGDAO
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Capacity:	2000m3	Material:	Other, Steel, Steel
Place of Origin:	Shandong, China	Brand Name:	BODA	Model Number:	TCZK

Product Description

poultry farm maize silo for sale

1. BODA hopper bottom steel silo series is specially designed by senior engineers in our company, with high-quality galvanizing board.

2. Hopper angles can be 45° and 60°,among which 60° conical bottom is usually used to store larger pellet and powder materials with high viscosity.

3. All BODA silos are precision engineered from high strength, 80mm x 14mm low profile corrugated steel plate, normally galvanised to 275 g/m2.

4. The life cycle of the silos can come up to 30-50 years long. The products are designed comply with the national standard of GB50322-2001.

5. BODA hopper bottom steel silos provide the best quality grain storage option available.Erection of the most popular 250t, 500t and 1,000t silos is straightforward,and can typically be completed in around 10 days per silo.

Details	Materials	Quality Standard	Features
Body Plate	By Hot Dip Galvanized Steel Plate, 275-600g/m2 Galvanization	China National Standard with Quality Report	Our Corrugated Steel Plate Production Line is controlled by advanced CNC equipments
Bolts and Screws	Hot Dip Galvanized, Strengthened, with hex flange for Max Sealing	Quality Strength Report	Hot dip galvanized with longer life
Enforcement Rib Stiffeners	Sidewall stiffeners are manufactured from min. 350 N/mm² tensile high strength steel . This type of stiffeners easily transit the vertical loads during loading or unloading, environment loads of the silo.	China National Standard with Quality Report	Can be inside or outside rib Rigorous calculation to meet full silo strength safety
Wind Ring	Hot Dip Galvanized For additional support for higher wind areas, the wind ring is attached directly to the stiffeners. The rings strengthen the silo providing reinforcement against damaging wind.	China National Standard with Quality Report	Rigorous calculation to meet the anti-wind needs for sea port area or windy area
Silo door with platform	A standard manhole door is located in the second ring of the silo. Double size door with strong frame and block system.	China National Standard with Quality Report	Easy for the ascendant to inspect and maintenance, ensure the safety of the silo.
Stairs	BODA offers both ladders and stairs as outside climbing options. All of them have handrail or safety guard.	China National Standard with Quality Report	Can be installed inside and outside of the silo, Easy for the ascendant to inspect and maintenance, ensure the safety of the silo.
Inside Ladder	Ladder inside silo, simple vertical or cage type ladder are available for your choice	China National Standard with Quality Report

Automatic-flow unloading;

save resources and costs;

Hopper angles can be 45° and 60°;

Could be movable;

easily to be installed;

Do not need a serious concrete, labor and energy cost;

less grain residues in steel grain silo;

Hopper structure prevents loss of time and money during the unloading period.

Bottom shape	Hopper Type	Flat Bottom Type
Capacity	≤1500t	≥1500t
Design view	Heavy structural “wide-flanged” columns Columns designed “X” bracing Pressure bearing is higher than the national standard, and safe enough.	Can be built by hopper concrete or flat cement based on your requirement and actual demand.
Silo Discharge	Hopper is with Rigorous Full Load Safety Calculation. BODA has 0 Silo Hopper Accidents and 0 Silo Accidents Can be made by concrete or steel	There will be one or more discharge holes on the bottom based on different materials and capacity.
Sweeper	Normally no need sweeper for hopper bottom silo except for high viscidity materials	Clean up residual easier China Famous Brand or France Brand

•Hopper bottom silos in capacities from 10 tonnes to 2,000 tonnes

•Flat bottom silos can reach the capacity of 10000 tonns

•Can be gas sealed for fumigation

•Insulation silo, stainless silo and welding silo are all available

•Complete grain storage, aeration, temerpature monitoring, level indicating, cleaning, drying, other handling and processing systems available. Elevators and conveyor systems from 10 t/hr to 1,000 t/hr

•Full installation service available

Installation: to guide the installation//send installation team//supply assembly drawing.
