Brief description: ZDJ-500 number plate making machine
ZDJ-500 paper plate machine is designed for the market requirement, It has integrated the pneumatic and the mechanic technologies, which makes it has the functions of faster working speed, higher safety-performance, safer operation and easier maintenance .
Standard ZDJ-500 paper plate machine has two working stations , each station install one set of mold and each station has separately PLC digital control and electric control.
It is widely applied to make paper plate (or aluminum foil laminated paper plate) in round (rectangle, square, circular, or irregular) shape. Machine speed changes against the material (paper) thickness and the plate size.
Paper Plate Size: | 4~10 inch (mold exchangeable); Max 300mm paper size |
Raw Material : | Paper/paperboard, Aluminum foil coated paper, One side PE coated paper or other; |
Suitable paper weight : | 100~500gsm (gram a square meter); |
Rated Speed : | 80~100 plates/minute (total two stations); 4800~6000 plates/hour (total two stations); |
Total Power : | 3 KW; |
Power Source : | 220V 50Hz or other required; (if your power different, Please tell us in advance) |
Total Weight : | 850 KG; |
Package Size (L * W * H) : | 1.75m * 1.65m * 1.8m ; |
Need Air source : | Working pressure 0.8Mpa, working air volume 1m3/minute; |
To make the large size plate, and the paper is very thick (over 600gsm), Available to make special machine and mold against the client's requirement, | |
Feature: number plate making machine
1.Adopt the advanced Program (PLC control the machine processing),
2.High efficient Pressurize Air-Cylinder (import from Taiwan) , Solenoid Valve (import from Taiwan),
3.Reliable machine design to keep the machine fast speed and durableness.
4.With the function of fault detection and auto stop;
5.Two times pressurizing Pressing to keep high quality plate/dish shape;
6.Each working station has separately control;
7.To make large size plate, special plate, paper thickness over 600gsm (800gsm~2000gsm),
Need a special plate machine (large frame, higher press power, etc.
Packaging&Shipping: number plate making machine
Company information
Our Services: number plate making machine
The good should be of good quality. But another important thing is the after service. Machines are machine, so they will have problems, even small problems. It is hard for customers to solve all the problems.
Our company will provide you good after services. We can help you solve the problem through video, email, phone. 24 hours hot line.
If needed, we can also let our engineer go to your country to solve the problem. We hope all the customer will satisfied with our machine and services.
If you are interested in our machines or have any questions,pls feel free to contact me .
Contact: Lin
Phone/viber/whatsapp: 86-15706776450
Email: info06@
Skype: wzqc006
Fax: 86-0577-65565872
Tel: 86-0577-65566111
