infrared soldering machine T-862

Technical Parameter

Work bench size 410x316mm
Rated voltage and frequency AC220-230v/AC110V   60/50Hz
Complete machine power 1600W
Preheating plate power 1500W
Preheating plate size 280x270mm
Preheating plate temperature adjustable 0-450°C

Main Components:

Preheating plate main body 1
Temperature sensor 1
PCB board holder 1
Power line 1
User manual (compact disc) 1

Main component function explanation:

  1. Adopt infrared weld technology which independent exploration.
  2. Use infrared heat,it is easy to cut through,heat proportion piercing tradition weld machine with sirocco.
  3. Easily operate.Just need one day training.Can operation this machine.
  4. No need weld tools,it can weld all the component of 15x15-25x25mm.
  5. This machine has 650W heating system.widely to 80x120mm.
  6. Infrared heating no have sirocco flow. Don't impact perimeter small component.Can suitable for all of the
  component,especially Micro BGA component.
