Specifications
1.High speed laser engraver2.suitable for non-metalic materials
3.Water cooling
4.DSP control system
5.1 year warranty
Reasonable structure enable the installation, inspection, maintenance and operation more ocnvenient, with the characteristic of high precision and speed.
The system of optical path adopts imported K9 reflected-lens and ZnSe focus lens which have the highest reflectivity and transmittance among the similar fittings.
Compatible with AutoCAD, CorelDRAW, Photoshop and so on
Advanced DSP control system with USB port off-line operating, PCI main line based on PC is also available.
Machine Description | EXLAS-1613 Laser Engraving and Cutting Machine |
Machine Performance: | |
Laser-type | Hermetic and detached CO2 laser tube |
Laser-power | 150W Reci laser tube with 10,000 lifespan(100W or 180W for option) |
Cooling Mode | Circulating-water-cooling |
Power Adjustment | 0-100% controlling, no segment and adjusting by software |
Machine Control and Drive | Speedy DSP controlling, stepper motor |
Max Engraving Speed | 48000mm/min |
Max Cutting Speed | 500mm/min(when cutting 10mm thick of acrylic) |
Repeating Location | 0.01mm |
Minimum Character | Chinese character 1.5mm, crisscross-row 1mm |
Max Power | 1800W |
Adjustable Up-down Distance of Laser Head | 40mm |
Working Travel Area | 1600x1300mm, 1650mm width with infinity material-feeding |
Table Area | 1650x1350mm |
Up-down Range of Working Table | Mechanical 260mm |
Working Voltage | AC220V 50Hz |
Working Environment | Temperature: 0-45oC, Humidity: 5%-95%, and congeal-water removed |
Controlling Software Language | English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
Dictate Format | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, Support AutoCAD,CoreDraw direct outputting |
Body Dimension (LxWxH) | 2200x1680x1300mm |
Packaging Dimension (LxWxH) | 2320x1900x1450mm |
Packaging | Wooden box |
Gross Weight | 564kg |
Machine Color | Customizable |
Delivery Time | 15 days |
Payment | T/T |
Optional Equipment | Rotary attachment |
Motorized up-down table | |
Water-cooling unit | |
Red-light position | |
Vacuum table | |
DSP Off-line operation with usb flash | |
Guarantee & Aftersales Service:
Laser tube 10,000 hours' working time
Comprehensive guarantee for half year
24-hour technical support by email or calling
User-friendly English manual for machine using and maintaining
