Specifications
1.Italy HSD spindle2.HIWIN rail guide
3.Vacuum Table/Dust collector/Automatic-mist sprayer
4.CE standard
1.X, Y, Z working area 2000 X 3000 X 200 mm
2.X, Y Movement Rack and Pinion transmission, Linear Square orbit (Taiwan Hiwin).
3.Z - Movement Imported ball screw made in Germany Linear Square orbit (Taiwan HIWIN)
4.Resolution Working Accuracy w air cooled HSD Italy Power MoReposition Accuracy
0.01 mm
0.05 mm
5.Machine Bed Structure Welded Steel / Cast Steel structure
6.Bed Type T Slot + Vacuum
7.Max. idling speed 50 m/min
8.Spindle Type 3.0,4.5kw water cooling / 3.0, 6kw air cooled HSD Italy
9.Spindle speed 0-24000 rpm / 0-18000 rpm
10.Working voltage Three Phase 380V/50Hz
11.Inverter Delta Taiwan
12.Drive Motors Stepper
13.Max. Power (without spindle) 1850 W
14.Max. Working Speed 25,000 mm/minute (good quality cutting bits ensured)
15.Command G code, HPGL, U00, mmg, plt
16.Operating system DSP/ Mach3/ NC Studio
17.Interface USB
18.Diameter of cutter Ø3.175-Ø12.7
19.Dust collector (complete) Yes
20.Work-holding T Slot + By suction (vacuum)
