Specifications
Newly developed EXLAS1280 Laser Engraving Machine,with CE1.Auto-focus
2.80-150W
3.Up-down moving table
4.Easy control
Newly developed EXLAS Laser
1) Working Travel Area: 1200 x 800mm,1250mm width with infinity material-feeding
2) Laser power: 80W (100W or 150W for option)
3) Laser type: carbon dioxide laser tube
4) Max Engraving speed: 1,200mm/s
5) Max Cutting speed: 500mm/min (80w, 10mm thick of acrylic)
6) Resetting positioning accuracy: <0.015mm
7) Cutting depth: acrylic 0-25mm
8) Min. shaping character: Chinese character 1.5mm, crisscross-row 1mm
9) Power supply: 220V±10% 50Hz or 110V±10% 60Hz
10) Gross power: 1,800W
11) Software supported: ArtCut, CorelDraw, PhotoShop, AutoCAD
12) Graphic format supported: *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, Support
13) Engraver for curve surfaces: we can add a Rotary attachment on the laser engrave/cutting machine, then the machine can engrave on cylinder objects.
14) Circulating-water-cooling: yes
15) Up-down Range of Working Table: Mechanical 260mm (up and down by hand)
16) Laser tube (life hours): 1,500hours
17) Equipment dimensions (mm): 1800x1180x1100mm
18) Assistant equipment includs: water pump, exhaust fan, aluminum alloy worktable
19) Optional spare parts: Rotary system, Motorized up-down table, Cooling water system, Red-light position bond with laser beam coaxially, DSP Off-line operation with usb flash
20) Recommended spare parts / consumables: laser tube and lens
21) English LCD
22) USB interface
23) Supports CAD and CorelDraw output directly
New improvements:
1New humanized design makes the machine body more compacted, saving working space.
2Improved structure enable the laser works more stable, better accuracy, lower noise.
3Itelligentized switch on door opening and closing, when you open the door, the machine stop beaming and travelling, you can resume working manually or by closing the top door.
4Itelligentized thermostat and water flowing switch to protect the laser tube, when the temperature goes above a certain point(can be fixed), the laser will pause and resume till temperature get normal, when thre is no water flowing, the switch will close and machine stop working,. This can enable the laser tube lifespan be extended.
5LED Lamp also fixed, with long lifespan and safe position.
