Help CenterHydraulic Cylinder Honed Tube and Cold Drawn Telescopic Pipe
Related Products
-
STKM13C Telescopic Cylinder Honed Seamless Steel TubeUS$ 0.8 - 1.2MOQ: 5 Metric Tons -
DIN 2391 Mechanical Carbon Seamless Steel Hydraulic Cylinder PipeUS$ 0.8 - 1.2MOQ: 5 Kilograms
-
ASTM1045 Cold Rolled Honed and Pneumatic Cylinder TubeUS$ 0.8 - 1.2MOQ: 5 Metric Tons
-
Cold Drawing Burnished Precision Seamless Steel TubeUS$ 0.8 - 1.2MOQ: 5 Metric Tons
-
ST37.4 Mechanical Using CDS Hydraulic Cylinder Honed TubeUS$ 0.8 - 1.2MOQ: 5 Metric Tons
ABOUT OUR COMPANY ,WE WANT TO SAY ----
We are Yantai Xinpeng Steel Pipe Co.,Ltd
♦Professional tube manufacturer which have over 20years experience
♦High reputation in tube world benefit by competitive price, quality and service.
♦Supply all kinds of steel pipes such as:
√ hot rolled/cold drawn seamless steel pipes
√ honed and skived pipes
√ cold drawn welded tubes(DOM tubes)
♦Our Website: https://img13.fr-trading.com
ABOUT OUR PRODUCT
Product Name |
Hydraulic cylinder honed tube and cold drawn telescopic pipe |
Standard: |
DIN 2391 ,ASTM A519 ,ASTM A106,EN 10305 |
Production according to customer requirements | |
Outer Diameter: |
30mm-250mm |
Wall Thickness: |
2mm-30mm |
Length: |
according to clients’ requirement |
Tolerance: |
H8-H10 |
Surface: |
According to the customer’s acquirement |
Outside Coating: |
oil, as per required by customer |
Test/Inspection: |
Ultrasonic test ; Hydrostatic test ,eddy current ,mechanical property test |
Payment terms: |
T/T,L/C |
Price terms: |
FOB,CIF |
Package: |
Standard export seaworthy package or as required. |
Delivery time: |
25days |
Place of origin : |
China |
Port : |
Yantai/qingdao |
Market: |
South America, Asia, Africa, Mid East, |
Productive technology: |
cold rolled, cold-drawing, hot piercing |
Min Order Quantity: |
Normally 5 Ton or according to customer's requirement. |
Production Capacity: |
500tons /month |
Ends: |
plain end or beveled end with cap or steel rings,thread with couplings or sockets,plastic bags, wooden boxes if required |
Certificate: |
ISO9001-2008 |
Steel Grade: |
10#-45#,st35-st52,q345,25Mn |
Qualification: |
Independent import and export qualifications |
Others: |
1.Special design available according to requirement; |
2.Anti-corrosion and high-temperature resistant with black painting; | |
3.All the production process are made under the ISO9001:2008 strictly. | |
4.We have professional pipe fittings and steel pipes production equipment in China, all of products are produced by ourself, so we can give you BEST price with BEST quality, hope we will co-operate with each other based on mutual benefits. | |
5. best Raw material | |
6.Abundant stock and prompt delivery | |
7.Rich supply and export experience, sincere service | |
8.Reliable forwarder, 2-hour away from port. |
SOME DIMENSION
40*50 |
90*110 |
140*170 |
190*215 |
40*55 |
95*110 |
145*170 |
190*220 |
50*60 |
95*115 |
150*170 |
190*225 |
50*65 |
100*110 |
150*175 |
200*220 |
55*70 |
100*114 |
150*180 |
200*225 |
60*70 |
100*115 |
155*180 |
200*230 |
60*75 |
100*120 |
160*175 |
200*245 |
60*78 |
100*125 |
160*180 |
200*250 |
63*73 |
105*125 |
160*185 |
220*250 |
63*75 |
110*125 |
160*190 |
220*270 |
63*76 |
110*130 |
160*195 |
225*250 |
63*78 |
115*130 |
165*190 |
240*273 |
65*80 |
115*135 |
165*205 |
250*290 |
70*80 |
120*140 |
170*200 |
250*300 |
70*82 |
125*140 |
180*200 |
260*300 |
70*85 |
125*145 |
180*205 |
280*323 |
70*90 |
125*150 |
180*210 |
280*355 |
75*90 |
130*150 |
180*215 |
300*350 |
80*92 |
130*155 |
180*220 |
200*213 |
80*95 |
130*160 |
185*205 |
200*216 |
80*100 |
135*160 |
185*215 |
250*266 |
85*100 |
140*160 |
185*220 |
|
90*105 |
140*165 |
190*210 |
THE TOLERANCE OF DIMENSION
ID size |
ID deviation (mm) |
|||
H7 |
H8 |
H9 |
H10 |
|
30 |
+0.021 0 |
+0.033 0 |
+0.052 0 |
+0.084 0 |
>30~50 |
+0.025 0 |
+0.039 0 |
+0.062 0 |
+0.100 0 |
>50~80 |
+0.030 0 |
+0.046 0 |
+0.074 0 |
+0.120 0 |
>80~120 |
+0.035 0 |
+0.054 0 |
+0.087 0 |
+0.140 0 |
>120~180 |
+0.040 0
|
+0.063 0 |
+0.100 0 |
+0.160 0 |
>180~250 |
+0.046 0 |
+0.072 0 |
+0.115 0 |
+0.185 0 |
>250~315 |
+0.052 0 |
+0.081 0 |
+0.130 0 |
+0.210 0 |
>315~400 |
+0.0527 0 |
+0.089 0 |
+0.140 0 |
+0.230 |
OUR PACKAGING AND SHIPPING
Please don’t worry that our products are packed, stored, transported according to the international regulation. We do care about the quality of our products; even some little details are paid attention to. We wrap the precision steel pipe with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement. Plus, our storage racks are made of wood. Any unwanted chemical reaction can be prevented.
OUR SERVICES
1. Cargo track service during transporting and feedback service after cargo is loaded on board
2. Flexible terms of payment by
3. Big discount for repeat customers
4. Smooth delivering procedure
5. Payment Terms: T/T , L/C And so on.
OUR PROCESSING
OUR TESTING
1.100% PMI,Spectro Chemical Aanlysis Test for Raw Material |
2.100% Dimension & Visual Examination |
3. Mechanical Properties Test Include Tension Test,Flaring Test (For Seamless tube/pipe)/ Flange Test (For Welded Pipe & Tube), Hardness Test ,Reversed Flattening Test |
4.100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test (ET or UT) |
5.Radiographic Test for Welded Pipe (shall be accordance with specification,or shall be as agreed upon between the purchaser and vendor) |
6.Straightness Test (optional) |
7.Roughness Test (optional) |
8.Intergranular Corrosion Test(optional) |
9.Impact Test (optional) |
10.Grain Size Determinations (optional) |
NOTES : ALL THE TESTS AND INSPECTION RESULT NEED TO BE SHOWED IN REPORTS ACCORDING TO STANDARD AND SPECIFICATION. |
OUR CDERTIFICATE
