Specifications
Wood Engraving CNC Router XYZ-2030:1.Italy HSD spindle
2.HIWIN rail guide
3.Vacuum Table/Dust collector/Automatic-mist spray
XYZ2030Woodworking CNC Router: which can save you more transport cost.
Description | Parameter |
X, Y, Z working area | 2000 X 3000 X 200 mm |
X, Y Movement | Rack and Pinion transmission, Linear Square orbit (Taiwan Hiwin). |
Z - Movement | Imported ball screw made in Germany Linear Square orbit (Taiwan HIWIN) |
Resolution Working Accuracy w air cooled HSD Italy Power MoReposition Accuracy | 0.01 mm 0.05 mm |
Machine Bed Structure | Welded Steel / Cast Steel structure |
Bed Type | T Slot + Vacuum |
Max. idling speed | 50 m/min |
Spindle Type | 3.0,4.5kw water cooling / 3.0, 6kw air cooled HSD Italy |
Spindle speed | 0-24000 rpm / 0-18000 rpm |
Working voltage | Three Phase 380V/50Hz |
Inverter | Delta Taiwan |
Drive Motors | Stepper |
Max. Power (without spindle) | 1850 Watts |
Max. Working Speed | 25,000 mm/minute (good quality cutting bits ensured) |
Command | G code, HPGL, U00, mmg, plt |
Operating system | DSP/ Mach3/ NC Studio |
Interface | USB |
Diameter of cutter | Ø3.175-Ø12.7 |
Dust collector (complete) | Yes |
Work-holding | T Slot + By suction (vacuum) |
The machine introduces DSP controlling system with advanced USD port which can ensure convenient and long-distance operating machine-off of computer.
The machine is suitable to process various cabinet doors, solid wood doors, computer tables, panel furniture, screens, craft windows, and etc. It can also be used for engraving and cutting of woody boards in large volume, together with 3D embossment, shadow carving, and so on.
