Mini PCB Experiment Router CNC Router DSP Control ZK-3030
- 380 Set / Sets per Month
- Shanghai/Guangzhou/Qingdao or according to your standard
- T/T D/P D/A Credit Card PayPal
- engraving cnc router,1325 woodworking cnc router 1300*2500*200
- engraving and milling machine,1325 woodworking cnc router 1300*2500*200
- engraver router,1325 woodworking cnc router 1300*2500*200
- dsp control cnc machine,1325 woodworking cnc router 1300*2500*200
- cnc woodworking router machine,1325 woodworking cnc router 1300*2500*200
- cnc woodworking router,1325 woodworking cnc router 1300*2500*200
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | Zhuoke |
Model Number: | ZK-3030 | Voltage: | AC380V/220V/110V or according to your need | Power(W): | 1.5kw |
Dimension(L*W*H): | 900*800*850mm | Weight: | 96kg | Certification: | CE |
Warranty: | One year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Mini PCB Experiment CNC Router DSP Control ZK-3030
Applicable Industries
To complete the production of single and double panel, to help students master the system board processes(cutting boards,carving,drilling,overhole plating). Provide a reliable platform for the training of the new technical
personnel according to factory.
Meet students’ electronic design, EDA practice, electronic design contest, course design, graduation design, innovative
practices, such as integrated design, innovative experimental requirements.
Provide the necessary conditions for students independent learning, cooperative learning, research study. Strengthen
students’ practical and creative ability. To culture from students to train engineers via electronic products from the principles of
design,process design, prototype production of the whole process,while learning and master the mechanical process plate process.
Technical advantages
In order to shorten the research and design time and see results as soon as possible, research institutions, universities, electronics
companies can adopt Zhuoke series PCB engraving machine.The time of product design developed is very long if sent to the printed
version of plant production, small trial is high cost and temporary modification of the printed version is also very troublesome.The
printed version of the production of other methods are very cumbersome and the printed version is not standardized.
Zhuoke series highprecision circuit board engraving machine with drilling, carving, line isolation, width setting, the whole map
and designated areas engraving, milling and shaped holes and other functions, you can also use multiple combination of
carving knives way to prevent a board spending a few hours, it has high performance. It takes just 12 minutes to make a simple circuit board and also just about 20 minutes to produce a very complex circuit board. With environmental performance, using physical engraving, free corrosion, avoid environment pollution, it is the most powerful, cost-effective CNC engraving machine in the PCB engraving machine industry.
PCB single panel making process
Cut the circuit board into the desired size, or the size of the board has been cut well-- designed in accordance with the engraving machine circuit diagram punch--hole of the device will be used to lay the hole plated circuit board on the wall of the hole copper--plated finish vias on the circuit board for carving, create a route--complete good soldered directly to the circuit board components.
Technical parameters
Certificate | CE | |
Effective working area | 300(X)mm*300(Y)mm*80(Z)mm | |
Max.thickness of the materials | ≤80mm(the distance between Z-axis and the bottom of the working station) | |
Moving method | Platform moving | |
Material | Whole cast aluminum | |
Working table | Aircraft aluminium T slot with PVC layer | |
Guide rail | Linear round guide rail | |
Transmission | Ball screw for X Y Z-axis (X Y Z-axis: #1605, TBI) | |
Driving mode | Stepper motor ( XYZ-axis: 57BYG-311) | |
Spindle motor | 1.5KW water cooling | |
Spindle collet type | ER 11 | |
Suitable cutter tools diameter | 3.175mm, 4mm, 6mm | |
Voltage | AC 220V 50/60Hz, single phase | |
Spindle speed | 0-24000rpm/min | |
Empty travelling speed | 0-8000mm/min | |
Engraving speed | 0-6000mm/min | |
Machine accuracy | 0.03mm | |
Resetting accuracy | 0.05mm | |
Diagonal error | 1mm | |
Resolution ratio | 0.005mm | |
Control system | PCI NcStudio or DSP or Mach3 | |
Designing software | Protel 99, Copper CAM | |
Minimum line diameter | 6-8mil | |
Minimum line spacing | 8mil | |
Minimum step distance | 0.003125mm | |
Motor wire | High soft specially for Numerical Control( 4*0.75) | |
Spindle wire | Shielding high soft (3*1.5) | |
Carving Instructions | G code *Uoo *mmg *plt HPGL | |
Running environment temperature | 0-45 °C | |
Relative humidity | 30%-75% | |
Tools | 24 pieces, 10 pieces drilling tools, 10 pieces engraving tools, 3 pieces corn milling tools, 1 piece bottom clearance tools | |
Accessories | Water pump(1), tools (24), power line, USB line, fixtures(4), user manual, software CDs, Ncstudio card(1), spanners(2), brush,collets(3), double faced adhesive tapes (2), water tank(1),etc. |
Other models
ZK-4040, 400*400mm , ZK-6060, 600*600mm ZK-6090, 600*900mm....
Packing: 0.6CBM, 96KG, one plywood case
Shipping: EXW/FOB/CIF/DDP/DDU... or according to your need
