Honed Astm A53 Schedule 40 Black Steel Pipe
- Qingdao
 - T/T

You May Like
Product Details
| Thickness | 2, 30 | |||
| Section Shape | Round | Outer Diameter | 30 - 250 mm | |
| Place of Origin | Shandong, China | Secondary Or Not | Non-secondary | |
| Technique | Cold Drawn | Certification | Other, ISO9001:2000 | |
| Surface Treatment | Other, honed | Alloy Or Not | Non-alloy | |
Product Description
Specifications
1.Grade:10#,20#.35#,45#,Q345,16Mn,25Mn,27SiMn,42CrMo,ck45,St45,St52etc2.ID:30-250mm
3.BKS honed steel pipe
Commodity name: honed astm a53 schedule 40 black steel pipe

Technical parameter:
1.Raw material:10#,20#,35#,45#,Q345,16Mn,25Mn,27SiMn,42CrMo,Aisi1020,Aisi1045,st35,St45,St52etc
2.ID:30-250mm
3.ID tolerance:H8,H9
4.Surface roughness:Ra 0.02— 0.4μm
5. Final supply condition:cold drawn and stress-relieved(BK+S)
6. Machining allowance:0.5-1.5mm
7.Wall thickness:10%×ID
Dimensions tolerance
OD(mm)  | ID (mm)  | Tolerance  | ||||
OD (mm)  | ID (mm)  | Wall thickness deviation (mm)  | Ovality (mm)  | Curvature(mm/m)  | ||
40-74  | 30-65  | ±.01  | -0.3,-0.5  | ≤0.5  | ≤0.1  | 0.3  |
74-98  | 65-85  | ±.01  | -0.4,-0.6  | ≤0.5  | ≤0.15  | 0.3  |
100-116  | 85-100  | ±.02  | -0.4,-0.6  | ≤0.6  | ≤0.15  | 0.3  |
124-134  | 110-115  | ±.02  | -0.6,-0.8  | ≤0.6  | ≤0.20  | 0.3  |
140-158  | 120-135  | ±.02  | -0.7,-0.9  | ≤0.8  | ≤0.20  | 0.3  |
165-176  | 140-150  | ±.02  | -0.7,-0.9  | ≤0.8  | ≤0.20  | 0.3  |
188-203  | 160-180  | ±.02  | -0.7,-0.9 Honed  | ≤0.8  | ≤0.20  | 0.3  |
Tolerance on ID
No.  | Inside diameter(mm)  | ID machining allowance(mm)  |
1  | 50-80  | 0.5-0.8  |
2  | 81-125  | 0.7-1.1  |
3  | 125-200  | 0.9-1.2  |
4  | 200-250  | 1-1.5  |
Other dimension can be customized  | ||
Commercial length
No.  | ID Min.(mm)  | Length(mm)  |
1  | 50  | 700—2000  |
2  | 63  | 700—3000  |
3  | 80  | 700—4000  |
4  | >90  | 700—6000  |
Other dimension can be customized  | ||
Delivey conditions:
- Standard packing with plastic caps and strapped bundles.
 - Commercial length 2000~10500mm,custom lengths upon request
 - Surface protection

we can supply all kinds of seamless steel pipes such as hot rolled seamless steel pipe,cold drawn seamless steel pipe,honed tubes,cold drawn welded tubes(DOM tubes).
Management System Certification:
Production Process:
- Pretreatment : Acid cleaning- Parkerizing


- Cold drawn/cold rolled

- Annealing furnace—— stress-relieving (+SR)

- Straightener—— Straightening/ Leveling

Dimension inspecting
- Sawing off not good parts


- Lathe

- Surface Polishing

CNC Skiving Roller Burnishing Machine
- Finished honed tube
