Help CenterA53b A106b Carbon Steel Seamless Tube Famous Manufacturer
Related Products
-
Steel Hydraulic Tube More Than 20 Years ExperienceUS$ 600 - 1,000MOQ: 5 Metric Tons -
Carbon Steel Pipe Astm A53 Using WidelyUS$ 700 - 1,100MOQ: 5 Metric Tons
-
Carbon Steel Pipe Astm A53 Professional FactoryUS$ 600 - 1,200MOQ: 5 Metric Tons
-
Cylinder Carbon Steel Pipe Astm A53 High ReputationUS$ 800 - 1,200MOQ: 5 Metric Tons
-
Ck20 Pipe Cold Finished and AnnnealedUS$ 600 - 1,000MOQ: 5 Metric Tons
Product Name |
a53b a106b carbon steel seamless tube famous manufacturer |
Outer Diameter |
30-250mm |
Wall Thickness |
2-30mm |
ID tolerance |
H7 H8 H9 |
Material Grade |
20# 45# Q345 25Mn 27SiMn E355 |
Package |
Standard packing or as client’s request |
Delivery Condition |
BK/BKW/BKS/GBK/NBK |
Delivery Time |
Within 20-30 days after receiving downpayment or as client’s request |
Trade Terms |
FOB Yantai, Qingdao, or as client’s request |
Payment Terms |
T/T or L/C or as client’s request |
Supply Ability |
500 metric tons/per month |
1.Hydraulic Cylinder Tube------Main products of Xinpeng
Used in the hydraulic cylinder of the heavy machinery, Cranes, excavator also forklifts.
We can work and get the mechanical property of the clients need and extended the life of the hydraulic cylinder.
2.Cold finished tube---- Widely Used. Processing range 30-300mm, biggest length is 11M.
3.SRB tube ----- used in Elevatorbuffer and Hydraulic Cylinder .
This kind tube have a better roughness inner the tube, ra0.2-0.4um and can use directly in the hydraulic cylinder tube. Range: ID 50-250mm and Length can work at most 6M.
The difference between precision steel pipe and seamless pipe?
1. the seamless steel tube with obvioue difference is that dimensional accuracy, can be up to 0.1mm.
2. high precision steel pipe diameter surface finish, the customer without processing can be used directly and ordinary seamless steel tube to the customer and lather, polishing processing.
3.Superior surface finish
4.Dimensional accuracy and excellent micro-structure uniformity
Technique and tolerance
Working Method |
Range |
Size of ID |
Tolerance |
|||||
ID tolerance |
WT(mm) |
Ovality |
Curvature |
|||||
H8 |
H9 |
H10 |
||||||
Cold Drawn |
25-250 |
>30-50 |
+0.0390 |
+0.0620 |
+0.1000 |
±5% to 7.5% ID>210mm ±10% |
≤0.10-0.20 |
0.3 |
Cold rolling |
25-150 |
>50-80 |
+0.0460 |
+0.0740 |
+0.1200 |
|||
Cold drawn-hone |
40-250 |
>80-120 |
+0.0540 |
+0.0870 |
+0.1400 |
|||
Cold drawn-SRB |
50-250 |
>120-180 |
+0.0630 |
+0.1000 |
+0.160 |
|||
Cold drawn-polish |
40-250 |
>180-250 |
+0.0720 |
+0.1150 |
+0.1850 |
|||
Cold drawn-polish-SRB |
50-250 |
Other size and technique parameter upon request |
||||||
Mechanical Property
Delivery Condition |
Cold drawn+stress-relieved(BK+S)(SR) |
Cold finished(hard)(BK) |
|||
Steel Grade |
Tensile strength (Rm Mpa)
|
Yield strength (ReH Mpa)
|
Elongation A5% |
Tensile strength (Rm Mpa)
|
Elogation A5%
|
20# |
≥520 |
≥375 |
≥15 |
≥550 |
≥8 |
45# |
≥600 |
≥520 |
≥10 |
≥640 |
≥5 |
16Mn(Q345B Q345D) |
≥600 |
≥520 |
≥14 |
≥640 |
≥5 |
25Mn |
≥600 |
≥510 |
≥15 |
≥640 |
≥5 |
27SiMn |
≥760 |
≥610 |
≥10 |
≥800 |
≥5 |
St45 |
≥520 |
≥375 |
≥15 |
≥550 |
≥5 |
E355(St52) |
≥600 |
≥520 |
≥14 |
≥640 |
≥5 |
SAE1026 |
≥600 |
≥510 |
≥15 |
≥640 |
≥5 |
Our Product Process
Packing&Shipping
1.Standard packing with plastic caps and strapped bundles.
2.Commercial length 2000~10500mm,custom lengths upon request
3.Surface protection
4.Marking as client's request
5.Within 20-30 days after receiving downpayment or as client's request
Application
Widely used in hydraulic system with precision steel tube, injection molding machine with precision steel tube, hydraulic press with precision steel tube, shipbuilding with steel tube, EVA foaming, hydraulic machinery, hydraulic cutting machine, shoe making machinery, hydraulic equipment, high pressure tubing, hydraulic tubing, card sets of joints, pipe joints, rubber machinery, forging machinery, casting machinery, engineering machiner...
Certification
Passing Verified System ISO9001, all of our products are in tight tolerance and high quality control to make sure to satisfy every client.
Our Service
1.passing ISO9001 system verified and in high quality control
2.with more than 20 years trading experience
3.alibaba trade assurance supplier
ducts with superior quality and competitive price
5.treating every client sincerely to satisfy them
Waiting for your contact!
