Help CenterASTM A106 GR.B A53 Sch40 Sch80 Sch160 Seamless Carbon Steel Gas Pipe and Oil Tube
Related Products
-
Non Alloy Bks Honed Tube for HydraulicUS$ 600 - 1,000MOQ: 5 Metric Tons -
Bks Honed Tube for Hydraulic in High Quality ControlUS$ 600 - 1,000MOQ: 5 Metric Tons
-
Astm A53 A106b Sch 40 Cold Seamless Steel PipeUS$ 600 - 1,250MOQ: 5 Metric Tons
-
Sch 40 Seamless High Precision Cold Finish Steel PipeUS$ 600 - 1,250MOQ: 5 Metric Tons
-
Seamless Steel Pipe SCH40 ASTM A106B Carbon Steel TubesUS$ 600 - 1,250MOQ: 5 Metric Tons
Commodity Specifications:
1.Commodity name: ASTM A106 GR.B A53 sch40 sch80 sch160 seamless carbon steel gas pipe and oil tube
2.Standard:GB/T8713,GB/T3639,DIN2391,EN10305,ASTMA519,ASTMA106-2006
3.Grade: 10#(St37/St37.2/St35.8),20#(aisi1020,ck20,St42-2/St45-8/St45-4),
45#(aisi1045,ck45,ASTM A1045),st52(16Mn,Q345D),25Mn(stkm13c-t),27SiMn
4.OD:30-250mm;
5.ID tolerance:H8,H9,H10
6. Wall thickness:10%×ID
7.Surface roughness:Ra 0.02— 0.4μm
8. Delivery condition:BK,BKW,BKS,GBK,NBK
9.Package: steel strip bundles, black paint coating, beveled ends or plain
10.Payment Terms: L/C or T/T(30% deposit and 70% balance against B/L copy)
11.Price Item:EXW,FOB,CFR or CIF
12.Delivery Time: Usually 15 working days after order confirmed& getting T/T deposit or original L/C
Mechanical Property:
Delivery Condition |
Cold drawn+ stress-relieved(BK+S)(SR) |
Cold fished (hard)(BK) |
|||
Steel Grade |
Tensile strength (Rm Mpa) |
Yield strength |
Elogation A5% |
Tensile strength (Rm Mpa) |
Elogation A5% |
20# |
≥520
|
≥375 |
≥15 |
≥550 |
≥8 |
45# |
≥600 |
≥520 |
≥10 |
≥640 |
≥5 |
E355(Q345B,St52) |
≥600 |
≥520 |
≥14 |
≥640 |
≥5 |
25Mn |
≥600 |
≥510 |
≥15 |
≥640 |
≥5 |
27SiMn |
≥760 |
≥610 |
≥10 |
≥800 |
≥5 |
ID Tolerance:
ID size |
ID deviation (mm) |
|||
H7 |
H8 |
H9 |
H10 |
|
30 |
+0.021 0 |
+0.033 0 |
+0.052 0 |
+0.084 0 |
>30~50 |
+0.025 0 |
+0.039 0 |
+0.062 0 |
+0.100 0 |
>50~80 |
+0.030 0 |
+0.046 0 |
+0.074 0 |
+0.120 0 |
>80~120 |
+0.035 0 |
+0.054 0 |
+0.087 0 |
+0.140 0 |
>120~180 |
+0.040 0
|
+0.063 0 |
+0.100 0 |
+0.160 0 |
>180~250 |
+0.046 0 |
+0.072 0 |
+0.115 0 |
+0.185 0 |
>250~315 |
+0.052 0 |
+0.081 0 |
+0.130 0 |
+0.210 0 |
>315~400 |
+0.0527 0 |
+0.089 0 |
+0.140 0 |
+0.230 0 |
Delivery condition:
1. NBK(+N)
after cold forming, eventually above phase transition point, in a protective atmosphere of annealing oxidation medium
2. GBK(+A)
after cold forming, annealing in non oxidizing medium protective gas
3. BK(+C)
the final heat treatment after cold forming, therefore small steel pipe plastically, the plastically degree does not guarantee
4. BKW(+LC)
after final heat treatment, a tiny cold drawing deformation, continue again when machining steel pipe allowed inside certain limits cold deformation(bending, flaring)
5. BKS(+SR)
have a stress relief after cold forming, heat treatment, steel pipe can be carried out within a certain limit in the appropriate processing again
Certificate:
Product Process:
About our company:
Established in Dec 1992, with registered capital of 5 million Yuan, Yantai Xinpeng Steel Pipe Co.,Ltd has more than 20 years experience in manufacturing and exporting steel pipe. Our company mainly produces various specifications of cold finished precision steel pipe, which are widely used in hydraulic Pneumatic cylinder for automobile, engineering machinery, textile machinery, printing machinery, oil drilling and other field.
We Have passed ISO9001 verified from 2008,each tube of ours is strictly in quality control that can assure the product quality of Xinpeng.
Application:
1.Hydraulic Cylinder Tube---Used in the hydraulic cylinder of the heavy machinery, Cranes, excavator also forklifts. Material is various, mainly STKM-13CT, ST52, CK45 and 1020. We can work and get the mechanical property of the clients need and extended the life of the hydraulic cylinder.
2.SRB tube ----- Used in Elevator,buffer and Hydraulic Cylinder .This kind tube have a better roughness inner the tube, ra0.2-0.4um and can use directly in the hydraulic cylinder tube.
Range: ID 50-250mm and Length can work at most 6M.
3.Cold finished tube---- Widely Used. Processing range 30-300mm, biggest length is 11M.
