4 Axis Mach3 Wood Engraving Machine ZKM-1325A
Machine featuers
1. Hiwin square guide rail for X Y Z-axis, long life time and high precision
2. Aluminum and PVC working table with T slot, more stable for the heavy materials.
3. Simple operation and installation, when delivery we will provide the videos for training.
4. 4 th axis, rotary axis mainly used for cylinder material engraving .with A-axis, when rotary axis working, X Y Z-axis all can move .
5.MAH 3 control system more convenient more functional.
Technical Data
Effective working area | 1300(X)mm*2500(Y)mm*250(Z)mm |
Max. thickness of the materials | ≤250mm(the distance between Z-axis and the bottom of the working station) |
Materials | Steel pipe welding machine bed |
Guide rail | Linear square guide rail |
Transmission | Rack for X Y-axis, ball screw for Z-axis |
Driving mode | Stepper motor |
Spindle motor | 3kw water cooling( or air cooling) |
Spindle speed | 0-18000rpm/min |
Rotary axis | diameter 150mm |
Engraving speed | 0-25000mm/min |
Voltage | AC 220V 50/60Hz or AC 380V 50/60Hz |
Resetting accuracy | 0.05mm |
Control system | NcStudio card |
Carving Instructions | G code *Uoo *mmg *plt HPGL |
Optional parts | DSP/Vacuum worktable/Rotary axis |
Reference machine photos
5.5kw water-cooling spindle
T-type gantry more stable
Rotary axis 150mm
MACH3 control system
Applications
Furniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates,
cupboard doors, interior doors, sofa legs, headboards and so on.
Advertising industry: advertising identification, sigh making, Acrylic engraving and cutting, crystal word making,
blaster molding, and other advertising materials derivatives making
