Specifications
1.Competitive Price Cold drawn hydraulic steel pipe factory2.Top quality
3.Golden supplier
4.OEM Acceptable
5.MOQ:20MT
Competitive Price Cold drawn hydraulic steel pipe factory
We supply all kinds of Steel Pipe products you need.
1.Raw material:20#.45#,Q345,16Mn,25Mn,27SiMn,42CrMo,etc cold drawn seamless pipes
2.ID:50-250mm
3.Final supply condition:BK+S
Honed cold drawn Pipe Parameter:
1.Raw material:20#.45#,Q345,16Mn,25Mn,27SiMn,42CrMo,etc cold drawn seamless pipes
2.ID:50-250mm
3.ID tolerance:H8,H9 Surface roughness:Ra 0.02—0.4μm
4. Final supply condition:cold drawn and stress-relieved(BK+S)
5. Machining allowance:0.5-1.5mm
6.Wall thickness:10%×ID
Tolerance on ID:
No. |
Inside diameter(mm) |
ID machining allowance(mm) |
1 |
300-80 |
0.5-0.8 |
2 |
81-125 |
0.7-1.1 |
3 |
125-200 |
0.9-1.2 |
4 |
200-250 |
1-1.5 |
Other dimension can be customize | ||
Commercial length
No. |
ID Min.(mm) |
Length(mm) |
1 |
50 |
700—2000 |
2 |
63 |
700—3000 |
3 |
80 |
700—4000 |
4 |
>90 |
700—6000 |
Other dimension can be customized | ||
Delivey conditions: According to the customer's Request
Usually
- Standard packing with plastic caps and strapped bundes.,standard weight approx 1500kg
- Commercial length 2000~10500mm,custom lengths upon request
- Surface protection.
Final Products
Any Intrest or need, please feel free to send us Inquiry!
We will give best quotation ASAP!
