Home > Products > Tyre Cutting machine > Large and mini size tyre shredder machine
Large and mini size tyre shredder machine
- 10 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Rubber Cutting Machine | Place of Origin: | Henan, China |
Brand Name: | JINZHEN | Model Number: | JZ-800 | Voltage: | 380V |
Power(W): | 104.5kw | Dimension(L*W*H): | 3500*2000*3000mm | Weight: | 8.5t, 8.5t |
Certification: | CE ISO, ISO, CE, BV | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Large and mini size tyre shredder machine
Our comany have several kinds of tire cutting machine which have different
functions, you can choose the best suitable one according to your actual needs.
Our tyre cuting machine also can cut large size tyre, which can customized accoring
to your actual needs.
Name of equipment | Instruction | |
Main equipment | Rubber powder machine | Model NO. : XKP-350 XKP-400 XKP-450 XKP-560 XKP-560D |
Auxiliary equipment | Tire Ring cutter | To remove the steel wire within the tire |
Tire Strip cutter | Cut tire into strips | |
Tire block cutter | Cut strips into rubber pieces | |
Magnetic separator | Extract and separate mental wire from the rubber power | |
Steel wire separator | Special for exract wires in the tire's circle | |
Rubber powder grinder | Deep process the rubber powder to 40-100 mesh |
Related Tire Cutting Machines
Tire shredder
Capacity | 2-4T |
Max diameter | 800mm |
Output diemension | 50*50mm |
Motor power | 49.5kw*2 |
Griddle power | 5.5kw |
Total power | 104.5kw |
Dimension | 3500*2000*3000mm |
Weight | 8.5T |
Ring Cutter Machine
Power | 4kw |
Material | Carbon steel |
Capacity | 30 tires/h |
Specification | 650-1200mm |
Dimension | 1700*1000*1700mm |
Weight | 650kg |
Strip Cutting Machine
Power | 4kw |
Weight | 850kg |
Dimension | 1080*800*1700mm |
Capacity | 2.5 T/H |
Specificaion | 50*80mm |
Tire cutter machine
Cutter Machine | Capacity | 0.8T/H |
Diemension | 1080*800*1480mm | |
Power | 5.5kw | |
Specification | 30*50*80mm | |
Weight | 8.5T |
Steel wire separator
Steel wire separator | Capacity | 20-40 tires/h |
Max diameter | 1200mm | |
Power | 7.5kw | |
Pressure | 13t | |
Cylinder telescopic length | 1200mm | |
Diamension | 4100*900*1750mm |
Installation & Commission of Tire Cutting Machine
1) Foundation drawings will be provided after making the order.
2) Engineers provided overseas installation and commissioning.
3) Trainings and other essential basic instructions will be provided.
After-sale service
1) We will send engineer to your site to install machine, train your workers and do
commissioning.
2) We offer one year warranty for our products.
