tire tyre recycling machine
1.Circle cutting machine
Take the waste tire put on the disk platform ,rotating disk garden among the handwheel,the four claws frame will get stuck inner circle of tire firmly, then starting power,platform working ,and the cutting tool will according needs to cut the tire,step-by-step, until the side of tire be cut, otherwise , the cutting tool is using cemented carbide material , hard and durable, it can be repeated use.
Items |
Parameters |
Dimension(L*W*H) |
1200mm*1200mm*1500mm |
Production Ability(tire/hour) |
40 tires//hour |
Motor Power |
3kw |
Frequency (HZ) |
50HZ |
Voltage (V) |
380V |
Weight (kg) |
300kg |
Tyre Applicable |
650mm--1200mm |
2.Strip Cutting Machine
Strips cutting machine can cut cycle machine to remove the wire tire sidewall cut into strips, and the width of the adjustable section. Two circular knives for special materials, hard and durable, can be used repeatedly grinding for no more than 1200 steel tires.
Items |
Parameters |
Dimension(L*W*H) |
1230mm*650mm*1580mm |
Production Ability(kg/h) |
1000kg/h |
Motor Power |
4kw |
Frequency (HZ) |
50HZ |
Voltage (V) |
380V |
Weight (kg) |
720kg |
Size of discharged material |
20mm--40mm |
Reducer Radio |
31.5 |
Speed reducer model |
350 |
Rotating Speed(round/min) |
1440r/m |
3.Block cutting machine
Cut 3-5cm strips into 3.5cm tire block
Function: Cut the tire into strips. Main Technical Parameters
Items |
Parameters |
Dimension(L*W*H) |
1000mm*960mm*1150mm |
Production Ability(kg/h) |
1000kg/h |
Motor Power |
4kw |
Frequency (HZ) |
50HZ |
Voltage (V) |
380V |
Weight (kg) |
420kg |
Size of discharged material |
20mm--40mm |
Rotating Speed(round/min) |
1440r/m |
4.Tire bead steel ring separator
(1) Function: cut the strips into pieces
(2) Main Technical Parameters
Items |
Parameters |
Dimension(L*W*H) |
1500mm*1100mm*1200mm |
Production Ability(tire/h) |
60t/h |
Motor Power |
15kw |
Frequency (HZ) |
50HZ |
Voltage (V) |
380V |
Weight (kg) |
1300kg |
Reducer Radio |
40.17 |
Rotating Speed(round/min) |
1440r/m |
Speed reducer model |
400 |
