CH-LA047 the low cost steel prefab house
the low cost steel prefab house
Instead of bricks and concrete used by traditional construction, CH-LA047 the low cost steel prefab house uses steel structure as the skeleton and sandwich panel as insulation. So, a low cost, long term durability and good thermal resistance can be obtained by the prefab house. And owing to the integrity roof, the low cost steel prefab house is completely waterproof. What the most exciting thing, is that the appearance and interior space division of the low cost steel prefab house can be customer designed and it can be moved and relocated anywhere you want.
CH-LA047 the low cost steel prefab house
CH-LA047 the low cost steel prefab house
CH-LA047 the low cost steel prefab house
Specification of CH-LA047 the low cost steel prefab house
Technical dates of CH-LA047 the low cost steel prefab house
Roof load |
75KG/m2 |
Floor load |
200KG/m2 |
Wind resistance |
Level 12 |
Seismic resistance |
Magnitude 10 |
Fire resistance |
Grade B1 |
Thermal conductivity |
<0.036W/(m×K) |
Noise reduction |
35~45db |
Lifespan of the prefab house |
25 years |
Sizes of CH-LA047 the low cost steel prefab house
20ft steel prefab house | ||||
Model |
External Size(L*W*H) |
Thickness of insulation(mm) |
Internal Size (L*W*H) |
Weight |
20FT-50 |
6058*2438*2896 |
50 |
5890*2260*2600 |
2000-2500KG |
20FT-75 |
6058*2438*2896 |
75 |
5840*2210*2550 |
|
20FT-100 |
6058*2438*2896 |
100 |
5790*2160*2500 |
|
40ft steel prefab house | ||||
Model |
External Size(L*W*H) |
Thickness of insulation(mm) |
Internal Size (L*W*H) |
Weight |
40FT-50 |
12116*2438*2896 |
50 |
11950*2260*2600 |
3500-4500KG |
40FT-75 |
12116*2438*2896 |
75 |
11900*2210*2550 |
|
40FT-100 |
12116*2438*2896 |
100 |
11850*2160*2500 |
|
Materials of CH-LA047 the low cost steel prefab house
Steel framework |
Top beam frame |
Q235, 5mm galvanized channel steel, color-painted |
Base beam frame | ||
Column | ||
Purlin |
Q235, 4mm rectangle steel pipe |
|
Wall |
External wall panel |
50/75/100mm PU/EPS/Rockwool/Glasswool sandwich pannel |
Internal wall panel |
50/75/100mm PU/EPS/Rockwool/Glasswool |
|
Decorative board |
PVC |
|
Roof & Ceiling |
Roof insulation |
50/75/100mm PU/EPS/Rockwool/Glasswool sandwich pannel |
Ceiling |
PVC panel or Gypsum board |
|
Floor |
Insulation layer |
50/75/100mm PU/EPS/Rockwool/Glasswool sandwich pannel |
Decorative board |
PVC, bamboo plywood or floor leather |
|
Door & Window |
External door |
Sandwich door with aluminum frame/security door |
Inner door |
Sandwich door with aluminum frame/PVC door |
|
Window |
PVC sliding window/Aluminum alloy window, shutter |
|
Optional system |
Water drain pipe |
16-20mm diameter PVC pipe |
Exhaust fan or air exchange hole |
steel or PVC, 250mm*250mm |
Application of CH-LA047 the low cost steel prefab house
Because of easy transportation and high remoldability, the low cost steel prefab house has been widely used as holiday house, villa, apartment, hotel, office, shop, exhibition room, medical station, booth, kiosk, showroom, restaurant, etc.
Why choose CH-LA047 the low cost steel prefab house?
1. High remoldability, the appearance and space layout of the steel prefab house from can be designed based on customer’s requirements;
2. Good thermal and sound insulation, good fire resistance and completely water proof, which can make the steel prefab house safe and comfortable;
3. Light weight but high strength enough for the steel prefab house to withstand 12 grade wind and 10 magnitude earthquake;
4. Easy transporting and relocating, you can locate the steel prefab house any where you want.
CH-LA047 the low cost steel prefab house
Why Us?
1. Professional technical support: First-class design team can give you technical advices.
2. Low cost: Modern enterprise management mechanism and professional production team ensure the low cost.
3. Standard quality control: Strict quality management system from raw materials to final products guarantees the high quality.
4. Shipment: We make every effort to ensure the optimal cargo arrangement and the lowest transportation cost.
5. All-around service: Professional sales team with more than 10 years’ experience makes the whole procedure high efficient and safe, and makes sure the perfect after-sales service.
Green (Tianjin) Technology Development Co., Ltd. locates in Tianjin with total investment of 25 million U.S. dollar. Our company has always been focusing on environment improving and energy saving products, steel further processing products and corresponding all-around services.
We strictly follow the modern enterprise management mechanism and have passed the authorization and audit of ISO system. Our company owns the qualification of Environmental Engineering Contractor (Grade Ⅲ), Steel Structure Engineering Contractor (Grade Ⅲ) and possesses more than 20 patents.
