CH-WH044 low cost prefab shipping container homes for sale china supplier

Item

 Category

Specification

Structure

ISO shipping Container

20ft: 6058x2438x2591mm

40ft: 12192x2438x2591mm

40HQ: 12192x2438x2896mm

Ceiling& wall (interior)

Simple decoration

Color coated steel sandwich panel

Insulation (  PU, EPS, rock wool can be chosen), Thickness (50, 75, 100mm can be chosen)

Luxury decoration

Light steel structure fixed on container corrugated wall

Plywood, plasterboard or fiber cement board (NO ASBESTOS) fixed on light steel structure

Insulation(PU, EPS, rock wool can be chosen), thickness (50, 75, 100mm can be chosen)

ICI painting as finish (Ceramic tiles for bathroom)

Others

ceiling: aluminum/ PVC/ others suspended ceiling, aluminum plastic composite panel, wooden, veneer, wall paper, customized

wall: aluminum plastic composite panel, wooden, veneer, wall paper, customized

external decoration (optional)

Customized

wooden cladding, PVC cladding, WPC cladding, aluminum cladding, decorative fiber cement board cladding

Floor

Customized

insulation (PU, EPS, rock wool  can  be  chosen) or nothing

solid wood, composite wood  floor, bamboo floor, carpet,  vinyl, ceramic tile, customized

Window

frame

PVC frame, aluminum frame can be chosen

glass

single tempered glass, double tempered glass can be chosen

fly mesh

stainless steel

security screen

stainless steel, galvanized steel, aluminum can be chosen

size

customized

Door

Customized

color coated steel sandwich panel door, aluminum door, solid wood door, composite wood door, PVC door, decorative steel door, fireproof steel door

Electricity

Customized

Distribution boxes with breakers

Lights, sockets & switches

Wire (concealed wiring or wall mounted wiring)

Water  plumbing

Customized

piping with sanitary (toilet, basin, shower etc)

Packing & Transportation

packing

plywood seal the wall opening (windows & doors etc)

transport

shipped as regular standard shipping container

Shipping Container homes Specification

20GP

40GP

40HQ

External Dimension(mm)

Length

6,058(0,-6)mm

12,192(0,-10)mm

12,192(0,-10)mm

Width

2,438(0,-5) mm

2,438(0,-5) mm

2,438 (0,-5) mm

Height

2,591(0,-5) mm

2,591(0,-5) mm

2,896(0,-5) mm

Internal Dimension(mm)

Length

5,898(0,-6) mm

12,032(0,-10)mm

12,032(0,-10)mm

Width

2,352(0,-5) mm

2,352(0,-5) mm

2,352 (0,-5) mm

Height

2,393(0,-5) mm

2,393(0,-5) mm

2,698(0,-5) mm

Door Opening(mm)

Width

2,340(0,-5)mm

2,340(0,-5)mm

2,340(0,-5)mm

Height

2,280(0, -5)mm

2,280(0,-5)mm

2,585 (0,-5)mm

Internal Capacity

33.2 cu.m /1,172 cu.ft

67.7cum/2,390cu.ft

76.4cum/2,700cu.ft

Maximum Gross Weight

30,480 kg

30,480 kg

30,480 kg

Maximum Payload

28,290kg

26,840kg

26,580kg

Performance

Roof bearing load

1.5KN/m2

Floor bearing load

3.0KN/m2

Wind resistance

12-Level

Seismic resistance

10-Magnitude

Fire resistance

B1 Grade

Temperature range

-40 to 50 oC

Thermal conductivity

<0.036W/(m×K)

Noise reduction

40db

Lifespan

Over 25 years
