CH-WH055 best modern 40ft container homes china for sale in alibaba
The description of modern 40ft container homes china
Different with brick or cement buildings, our modern 40ft container homes china adopt light steel as skeleton and sandwich panels as insulation wall. Our modern 40ft container homes china are low cost and can be conveniently moved to anywhere. The size, appearance and internal space division of our modern 40ft container homes china can be customized; you can freely use your imagination to get a unique and eye-catching modern 40ft container homes china.
Detail information of modern 40ft container homes china
Ourmodern 40ft container homes china | ||||
Model |
External Size |
Thickness of |
Internal Size |
Weight |
(L*W*H) |
insulation(mm) |
(L*W*H) |
||
40FT-50 |
11600*2250*2650 |
50 |
11450*2100*2500 |
4000-4500KG |
40FT-75 |
11600*2438*2896 |
75 |
11400*2050*2450 |
|
40FT-100 |
11600*2438*2896 |
100 |
11350*2000*2400 |
|
The material of modern 40ft container homes china
Steel framework system of our modern 40ft container homes china | |
Top beam frame |
Q235, 4mm or 5mm galvanized channel steel |
Base beam frame | |
Column | |
Purlin |
Q235, 4mm or 3mm steel pipe |
Wall system of our modern container homes | |
Steel wall |
1.6mm or 1.8mm color steel sheet |
Sandwich panel wall |
50/75/100mm PU/EPS/Glass wool sandwich panel |
Glass wall |
Transparent glass |
Decorative board |
PVC |
Roof system of our modern 40ft container homes china | |
Steel roof |
1.6mm or 1.8mm color steel sheet |
Sandwich panel roof |
50/75/100mm PU/EPS/Glass wool sandwich panel |
Ceiling |
PVC panel or Gypsum board |
Floor system of our modern container homes | |
Decorative board |
PVC, bamboo plywood or floor leather |
Bearing plate |
1.6mm or 1.8mm color steel sheet |
Insulation |
50/75/100mm PU/EPS/Glass wool |
Optional systems of our modern container homes | |
Electric system |
Customized design |
Drainage system |
16-20mm diameter PVC or steel pipe |
Exhaust fan or air exchange hole |
steel or PVC, 250mm*250mm |
The advantage of our modern 40ft container homes china
1. Easy to assemble and disassemble: The modern 40ft container homes china can be assembled and disassembled for dozens of times and can be reused for many times. And the assembling only needs simple tools and doesn’t need power source. The connections of the pieces of the prefab container homes 40ft all adopt plugs or screw connections.
2. Strong Structure: Our modern 40ft container homes china adopts steel frame structure, therefore the modern 40ft container homes china is stable and in line with the designing code of building structure. (The light steel and the flexible structure is more reliable and safer, which can make it to meet the design criteria based on the construction requirements.)
Performance |
Roof bearing load |
1.5KN/m2 |
Floor bearing load |
3.0KN/m2 |
|
Wind resistance |
12-Level |
|
Seismic resistance |
10-Magnitude |
|
Fire resistance |
B1 Grade |
|
Temperature range |
-40 to 50 oC |
|
Thermal conductivity |
<0.036W/(m×K) |
|
Noise reduction |
40db |
|
Lifespan |
Up to 25 years |
3. Durable: The steel frame parts of modern 40ft container homes china are all processed with anti-corrosion coating and it can be used as long as 20 years.
4. Good insulation for heat and sound, good fireproof and waterproof: The adopted sandwich panels of our modern 40ft container homes china have a good heat insulation, with thermal conductivity lower than 0.036W/ (m×K). The fire resistance is B1 grade and the noise reduction reaches up to 40db. That can make your modern 40ft container homes china safe, quiet and comfortable. And thanks to the use of integrated roof and drainage system, our modern 40ft container homes china is completely waterproof.
5.Strict quality control system: We have the strict quality control, and unqualified product can’t be loaded. This is the tenet of our factory. We do the strict testing procedures on each modern 40ft container homes china before it is loaded, to ensure 100% quality assurance.
About us
Green (Tianjin) Technology Development Co., Ltd. locates in Baodi Jiuyuan Industrial Park with total investment 25 million U.S. dollar. Our company has always been focusing on environment improving, energy saving products, steel further processing products and corresponding all-around services. Our company owns the qualification of Environmental Engineering Contractor (Grade Ⅲ), Steel Structure Engineering Contractor (Grade Ⅲ). We have passed the authorization and audit of ISO system and possess more than 20 patents.
If you are interested inour modern 40ft container homes china, please feel free to contact with me. Hope we can build long term cooperation and have the fruitful future.
