Help CenterIntel D525 Industrial Network Security Firewall pc Motherboard With 6 Lan DC Power
Related Products
-
4 Lan Intel Atom D525 Cheap Industrial Firewall Computer MotherboardUS$ 1 - 90MOQ: 1 Piece -
4 Ethernet Ports D525 Embedded Cheap Industrial Network Security Firewall pc MotherboardUS$ 1 - 90MOQ: 1 Piece
-
4 Lan Intel D525 Cheap Industrial Network Security Firewall Mini pc MotherboardUS$ 1 - 90MOQ: 1 Piece
-
4 Lan Ports X86 Atom D525 Embedded DC Power Cheap Industrial Network Security Firewall MotherboardUS$ 1 - 90MOQ: 1 Piece
-
Intel D525 Embedded 6LAN Firewall Hardware Barebone System Solid Long Life CapacitorUS$ 1 - 199MOQ: 1 Piece
6 Lan Intel atom D525 network security firewall motherboard
|
Processor |
CPU |
Intel Atom D525 |
Frequency |
Dual core 1.8Ghz |
|
Chipset |
ICH8M |
|
TDP |
|
|
Memory |
Slot |
1*SO-DIMM,DDR3 800 MHz Memory |
capacity |
MAX to 4GB |
|
Storage |
connector |
2*SATA2.0 |
1*CF | ||
1*MINI PCIE (For WIFI) 1*SIM | ||
Display |
chipset |
CPU integrated HD Graphics |
output |
VGA header |
|
LAN |
chipset |
6*Intel 82583V 1000M |
connector |
6*RJ45 |
|
Audio |
chipset |
|
connector |
|
|
|
I/O |
com |
1*COM header |
Lpt |
|
|
USB |
2*USB2.0,1*USB2.0 header (can expand to 2*USB2.0) |
|
GPIO |
|
|
|
Header |
1*IDE PWR 1*Reset 1*LED 1*USB 2.0 header 1*12PIN VGA 1*Sata-PWR 1*4pin DC 1*CLR-CMOS jumper 1*SYS-FAN 1*PS2 header
|
|
Power |
power supply |
1*DC IN 12V/5A 1*4PIN ATX |
OS |
Version |
Win7/Win8/Linux |
BIOS |
|
AMI BIOS |
working environment |
working temp |
-10~60℃ |
storage temp |
-10~70℃ |
|
relative humidity |
5%-95% non-condensing |
|
Form factor |
size |
180*200mm |
Carton box packaging, shipped by door to door express (Fedex, Dhl,Ups,Tnt etc,) or air
We can give you 1 year warranty and 1% RMA,
To assure the quality, we usually do full test befor shippment to avoid the quality issue
24*7 hotline for inquiry, if you have any questions about our products, you can contact us any time.
1.What is your payment terms ?
T/T, Paypal ,westunion ,money gram for sample or small order
2.What is your lead time?
3-5 working days after receipt of payment
3.Do you have warranty about your products?
Yes, 1 year
4. Can you do customlized serive ?
Yes. We can add your logo on our products. or we can design as per your requirements
OEM and ODM serive are available
Application
