Nano ITX 12*12cm 1037u hdmi embedded X86 linux motherboard
Intel celeron dual core 1037U 1.8GHz processor,Intel NM70 chipset ,interated Intel HD Graphic ,8GB notebook RAM,HDMI/VGA,onboard Realtek 8111E lan ,support M-SATA/WIFI,size:120x120mm.
Processor |
CPU |
support intel Celeron 1037u |
Frequency |
Daul core 1.8GHZ |
|
Chipset |
HM65 |
|
TDP |
17W |
|
Memory |
Slot |
1*SO-DIMM,DDR3 1600[3F6MHz Memory |
Capacity |
MAX to 8GB |
|
|
Storage |
Connector |
1*SATA2.0 |
1*MSATA | ||
1*MINI PCIE supprt WIFI | ||
Display |
Chipset |
cpu integrated HD-Graphics |
Output |
VGA/HDMI/VGA Header |
|
LAN |
chipset |
Realtek 8111E 1000M |
Connectore |
1*RJ 45 |
|
Audio |
Chipset |
Realtek ALC 662 HD |
Connector |
1*LINE OUT |
|
|
I/O |
COM |
1*com header |
LPT |
|
|
USB |
2*USB2.0,1*USB2.0 header(expand to 2*USB2.0 connector ) |
|
GPIO |
|
|
Header |
1*USB 2.0 1*12PIN DEBUG 1*12 PIN VGA 1*MIC-IN 1*CLR-CMOS 1*SATA-PWR 1*SYS-FAN 1*F-PANEL 1*CIR 1*COM |
|
Power |
power supply |
DC IN 12V |
OS |
|
Win7/win8/xp/linux |
BIOS |
|
AMI BIOS |
|
Working Environment |
working temp |
-10~60 degree |
storage temp |
-10-70 degree |
|
Relative humidity |
5%-95% non-condensing |
|
Form factor |
Size |
NANO-ITX 120*120mm |
Carton box packaging, shipped by door to door express (Fedex, Dhl,Ups,Tnt etc,) or air
We can give you 1 year warranty and 1% RMA,
To assure the quality, we usually do full test befor shippment to avoid the quality issue
24*7 hotline for inquiry, if you have any questions about our products, you can contact us any time.
1.What is your payment terms ?
T/T, Paypal ,westunion ,money gram for sample or small order
2.What is your lead time?
3-5 working days after receipt of payment
3.Do you have warranty about your products?
Yes, 1 year
4. Can you do customlized serive ?
Yes. We can add your logo on our products. or we can design as per your requirements
OEM and ODM serive are available
