H87 DVR ATX industrial motherboard with 24 usb
IntelH87 chipset ,LGA1150,support i3/i5/i7 processor .VGA+HDMI+LVDS,,1*PCIE 16X+1*PCIE 1X,20*USB3.0,6*COM,10*SATA,support RAID,watch dog,2*INTEL 1000M ,support large capacity storage, transmiting,
Display,24Pin ATX+4Pin ATX-12V,size:300X210X38MM.
|
procesor |
CPU |
support Intel 4th Haswell platform core i3/i5/i7 processor |
Frequency |
Depend on CPU |
|
Chipset |
Intel H87 |
|
TDP |
Depend on CPU |
|
Memory |
slot |
4*DDR3 DIMM Memory |
capacity |
MAX to 32GB |
|
|
Storage |
connector |
10*SATA |
| ||
| ||
Display |
chipset |
CPU integrated HD Graphics |
display |
HDMI,VGA,HDMI header,VGA header,LVDS header |
|
LAN |
chipset |
1*Intel 82583 |
connector |
1*RJ45 (2 *RJ45 for options) |
|
Audio |
chipset |
1*Realtek ALC662 HD |
conector |
1*Line-out,1*Line-in,1*mic-in,1*Audio,1*Speaker |
|
|
I/O |
com |
6*COM (5*COM header) |
lpt |
2*LPT(1*LPT header) |
|
USB |
20*USB3.0 +4*USB2.0 |
|
PCIE |
1*PCIE 16X 1*PCIE 1X |
|
|
Header |
1*PS/2 connector |
|
Power |
power supply |
24+4PIN ATX 4PIN ATX 12V |
OS |
version |
Win7/Win8/Linux |
BIOS |
|
AMI BIOS |
|
working environment |
working temp |
-10~60℃ |
storage temp |
-10~70℃ |
|
relative humidity |
5%-95% non-condensing |
|
Form factor |
size |
300X210X38MM |
Carton box shipped by express or air lead time 3-7 days
We can give you 1 year warranty and 1% RMA,
To assure the quality, we usually do full test befor shippment to avoid the quality issue
24*7 hotline for inquiry, if you have any questions about our products, you can contact us any time.
1.What is your payment terms ?
T/T Paypal westunion money gram for sample or small order
2.What is your lead time?
1-3 working days after receipt of payment
3.Do you have warranty about your products?
Yes, 1 year
4. Can you do customlized serive ?
Yes. We can add your logo on our products. or we can design as per your requirements
OEM and ODM serive are available
