Industrial Economical Pressure TransducerMeasuring range:0.5Mpa~60MPa
Industrial Economical Pressure Transducer
Introduction
CS-PT1000 series of pressure transmitters are cost-effective products featuring mass production and low cost. They are widely used to detect the pressure of gas and liquid like water and nature gas,
The product are made of stainless steel, the pressure sensing elements are selected from well-known international brands,. Special circuits are adopted to adjust zero and full range conveniently. The products have been approved with CE, intrinsically safe, and explosion-proof certificates.
Customized structures and outputs formats can be designed according to special application requirement, in addition to standard products.
Technical parameters
Parameters |
Value |
Note |
||
Measure Range |
0.5Mpa~60MPa |
1MPa≈145PSI |
||
Overload Pressure |
1.5×RP(rated pressure) |
|
||
Broken Pressure |
2.5×RP(rated pressure) |
|
||
Accuracy |
±0.5% F.S ( MARS & PT300 series have higher accuracy) |
|
||
Stabilty |
Typical 0.25%F.S, Max 0.4%F.S |
|
||
Operate Temprature |
-40℃~85℃ |
|
||
Compensation Temprature |
-10℃~70℃ |
|
||
Media Compatibility |
Corrosive medium compatible with Cr18Ni9Ti, ceramics |
|
||
Wire |
Two-wire |
Three-wire |
|
|
Output Signal |
4~20mA |
0~5V |
0~10V |
|
Power Supply |
12~30Vdc |
10~30Vdc/ac |
12~30Vdc/ac |
dc/ac means dc and ac are all usable |
Load Resistance |
(U-10)/0.02(ohm) |
>20kohm |
|
|
Insulation |
>100M ohm@50V |
|
||
Elec. Connect |
DIN43650, Shell protection IP65 |
Hirschmann Plug(S) |
||
|
GX16-7, Shell protection IP45 |
Quick Access Plug(K) |
||
|
Wire protection (Five), Shell protection IP68 |
|
||
Pressure Port |
M20×1.5, G1/2, G1/4, NPT1/2, NPT1/4 |
|
||
Response Time |
10ms |
|
||
Pressure Form |
Gauge G, Absolute A |
|
||
Compliant |
CE |
|
||
EMC |
EMI: EN50081-1/-2; EMS: EN50082-2 |
|
||
